8.4

Resolving Liquid Leaks

When
Parts and additional items required
Preparations
Follow these steps
Diode Array/Multiple-Wavelength Detectors (VC-D11, VC-D12, VF-D11)
Operating Manual
The leak sensor is wet. The leak sensor reports leakage.
• Replacement part as required
• Cloth or tissue
When resolving leakage, observe the safety guidelines and general rules
for maintenance and service as presented in
(} page 113).
1. Locate the source of the leak. Leakage usually occurs at a
connection. However, leakage may also have occurred inside the
flow cell.
Location of the leak
Flow cell inlet and/or outlet
Leak tray but not flow cell inlet or outlet
4. With a cloth or tissue, thoroughly absorb all liquid that has collected
in the leak tray and under the leak sensor. Be careful not to bend the
sensor.
5. Allow the sensor to adjust to the ambient temperature for a few
minutes.
6. If leakage is no longer reported, you can resume operation.
See also
2
Installing a Flow Cell (} page 62)
2 Removing the Flow Cell (} page 134)
8 • Troubleshooting
Maintenance and Service
Steps
1. Tighten the connection where liquid is
visible.
2. If the connection seems tight but is still
leaking, remove the capillary/waste
line and check for damage.
3. If the capillary/waste line is damaged,
replace the respective component.
4. If the connection unit or the capillary
between the flow cell and the
connection unit is damaged, replace
the flow cell.
Leakage may have occurred in the flow
cell.
1. Remove the flow cell from the
detector.
2. Inspect the flow cell for signs of
leakage.
3. If necessary, replace the flow cell.
