6.2 REPLACING SEED DISC
1- Loosen the two securing knobs to remove the lid from its original place (Fig. 6.9).
2- Pull the seed selector (1, Fig. 6.10) to remove it from the securing groove. Then loosen the
knob of the seed ejector in order to remove it (2, Fig. 6.10).
3- The seed disc is secured magnetically. Use
both hands to pull the disc to remove it.
Once it has been removed, the vacuum
chamber of the metering box will be visible
(Fig. 6.11).
4- Place the selected seed disc.
5- Place both the seed selector and the seed
ejector back. Use the knob to fix the seed
ejector at the correct position as shown in
section 6.3.2 Adjusting the seed ejector.
6- Place the lid back and fix it using the two knobs.
To select the correct seed disc, see the tables in sections 6.1.1 CHAIN GEARBOX or 6.1.2 AUTOMATIC
GEARBOX.
USE ALWAYS THE SUITABLE
SEED DISCS FOR EACH TYPE OF
SEED (SEE SECTION 3.6 METE-
RING BOX).
Fig. 6.9
IMPORTANT: fit the tips of
t the seed disc's reverse into the
holes of the metering box's va-
cuum chamber (3, Fig. 6.11).
Fig 6.12
1 2
3
41
ADJUSTMENTS
Fig. 6.10
3
Fig. 6.11
