ADJUSTMENTS
Next to each dosing device, there is an adjusting wheel (A, Fig. 6.137). Turn it to adjust the heli-
cide distribution.
The ratchet has a adjusting scale marked from A to E, and the nut has 10 numbers for each letter.
For each dosing device adjust the ratchet's letter to the nut's number (A, Fig. 6.137).
IT IS NOT RECOMMENDED USE POSITIONS LOWER THAN B/0 SINCE THEY MAY RESULT IN AN
IRREGULAR DISTRIBUTION.
To empty the hoppers of the insecticide micro granulator and the helicide micro granulator, T
see sections 8.3 INSECTISIDE MICRO GRANULATOR'S AND/OR HELICIDE MICROGRANULATOR'S
HOPPERS.
Also, the machine is equipped with a double cog that allows you to make a change the metering
box's transmission. In this way, there is a wider range of possible dosages. Previous table shows
both possible transmissions P.S=12Z P.E=22Z or P.S=22Z P.E=12Z.
In order to change the transmission ratio or exclude it, see section 6.19.1 CHANGING THE MICRO-
GRANULATOR'S TRANSMISSION and/or 6.19.2 EXCLUDING THE MICROGRANULATOR.
