Main Techincal Indexes And Parameters; Maintenance - CDP 7000 Operation Manual

Important: This breathalyzer includes four AA batteries of 1.5 V. You may also use 4 Ni-Cd
rechargeable batteries with a voltage of 1.2 V and normal capacity above 2000mA for
durability purposes. If you select Ni-Cd batteries, the battery type must be changed in the
breathalyzer program or the battery indication will be incorrect. To do this, power on the unit,
then press and the right button
the battery and voltage setup menu. Check the nominal voltage on the battery, then press
the right button
to exit this menu.
8. MAIN TECHNICAL INDEXES AND PARAMETERS
Model
Sensor type
Measurement range
Warm-up time
Response time
Continuous working time
Dimensions
Net weight
Recommended calibration periods:
9. CARE AND MAINTENANCE

Please read this manual carefully and follow all instructions before operation.

Avoid hitting or dropping the unit.

If necessary, use a humid cloth to clean the unit. Do not use water, solvents or
conventional cleaners which could damage the unit.

If the breathalyzer is used with very low batteries, the results could be erroneous.
Always use the batteries recommended by the manufacturer.
to confirm the selection. You may now save the new setup. Press
Table 3.
CDP 7000
Fuel-cell alcohol sensor
0～2.000mg/L（0～440mg/100ml）
Warm-up not necessary
<1s
100-2000 times (depends on battery capacity）
L×W×H: 284×68.5×74mm
About 400g（with 4 batteries）
6-12 months
simultaneously during one second. You will see
8
