Lopi 564 Installation Instructions

Lopi 564 Installation Instructions

Black glass fireback

Advertisement

Quick Links

Compatibility
564 SS
564 HO Ember-Fyre (you must order hearth plate sku# 250-03768)
564 HO Dancing-Fyre (you must order hearth plate sku# 250-03768)
NOTE: These firebacks do not work with 564 HO Diamond-Fyre
GLASS FIREBACK WARNINGS
HANDLING THE FIREBACKS: The glass firebacks are fragile – especially the edges. Take care to prevent
contacting/scraping the glass against metal or rough surfaces. You may wish to lay out a blanket during
installation in case you need to set the firebacks down.
We recommend the use of gloves and safety glasses during the installation of the glass firebacks.
CLEANING
These firebacks require periodic cleaning. Do not use ammonia-based cleaners (this may cloud the glass). We
recommend ammonia-free glass cleaner (i.e. vinegar and water) to clean the fireback.
Install the firebacks after the fireplace is in position.
Install the firebacks before installing the log set.
Installation
WARNING Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
1. Access the firebox (see the installation manual for details).
2. Remove the grate (see instructions below).
1/4" Nutdriver
Remove the grate
(replace after fireback installation).
Page 1 of 2
564 Black Glass Fireback
Installation Instructions (96100205)
17602050 - 9/25/18
Packing List
(1) Rear Fireback
(2) Side Firebacks
© Travis Industries, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 564 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lopi 564

  • Page 1 564 SS (1) Rear Fireback   564 HO Ember-Fyre (you must order hearth plate sku# 250-03768) (2) Side Firebacks  564 HO Dancing-Fyre (you must order hearth plate sku# 250-03768) NOTE: These firebacks do not work with 564 HO Diamond-Fyre GLASS FIREBACK WARNINGS HANDLING THE FIREBACKS: The glass firebacks are fragile –...
  • Page 2 “a” to secure the side firebacks.. On older 564 fireplaces the glass clip is not long enough to contact the side firebacks. For these fireplaces you can order new clips (250-04787) or bend the existing clips outwards as shown below.
