Summary of Contents for SOLZAIMA K50
- Page 1 Pellet Stove Instruction Manual Model Europa Read the instructions carefully before installing, operating and maintaining the equipment. The operating instructions are an integral part of the product. Mod.928-B...
- Page 2 No. 305/2011) and are CE approved; * The pellet stoves were built in accordance with EN 14785:2008. * SOLZAIMA is not responsible for any damage to the equipment when it is installed by unqualified personnel; * SOLZAIMA is not responsible for any damage to the equipment when the installation and rules indicated in this Manual are not respected;...
-
Page 3: Table Of Contents
Index Package contents ........................ 5 1.1. Unpacking the stove ..................... 5 Safety warnings ........................5 Advice on action in the event of a fire in the chemney (including equipment)....6 Technical characteristics ..................... 7 Installation of the pellet stove .................... 8 5.1. - Page 4 12.2.1. Additional cleaning ..................32 12.2.2. Cleaning the fume passage K50..............32 12.2.3. Cleaning the fume circuit K50 ................ 33 Alarm / Failure / Recommendation List ................36 Installing and operating with the remote control ............. 38 14.1. Installation instructions for the external control unit..........39 Maintenance Plan and Log ....................
- Page 5 As a result of the persistence and unconditional support of its network of partners, Solzaima is today a leader in the production of biomass heating, the best example of which are central water heating stoves and its range of pellet stoves.
-
Page 6: Package Contents
1. Package contents The packaging of the equipment has the following content: - Pellet stove model K50 - Access brochure to the online instruction manual; - Power cord; - Infrared remote control; - Cleaning bar handle. 1.1. Unpacking the stove In order to unpack the equipment, you must first remove the retractable bag around the cardboard box. -
Page 7: Advice On Action In The Event Of A Fire In The Chemney (Including Equipment)
It is forbidden to cover or reduce the dimensions of the air intakes at the installation site; The pellet stove is an equipment that needs air to carry out proper combustion, so that any leakage of the room where the equipment is located or the existence of other sources of air extraction in the room may prevent the correct operation of the equipment;... -
Page 8: Technical Characteristics
Close the doors and windows or partition where the fire broke out. Turn off the power and turn off the gas before leaving your home. Once outside, you should wait for the firefighters and be ready to give you the following information: location of the fire, possible materials that are burning and what they can do to prevent the progression of the fire. -
Page 9: Installation Of The Pellet Stove
Front Back Side Figure 2 – Dimensions of the K50 pellet stove (e.g. Europe model) 5. Installation of the pellet stove Before starting the installation, perform the following actions: - Check immediately upon receipt that the delivered product is complete and in good condition. -
Page 10: Installation Requirements
5.1. Installation requirements The minimum distances from the pellet stove to particularly flammable surfaces are shown in figure 4. At the top of the stove it is necessary to keep a minimum distance of 100 cm from the ceiling of the room, especially if they contain flammable material in their composition. The base on which the stove rests must not be made of combustible material (e.g. -
Page 11: Installation Of Ducts And Smoke Exhaust Systems
5.2. Installation of ducts and smoke exhaust systems: The construction of the gas exhaust pipe must be suitable for this purpose in accordance with the local requirements and the applicable regulations. Important! An inspection T- with a hermetic cap should be inserted at the exit ... - Page 12 Figure 6 shows the basic requirements for the installation of the stove's chimney. Figure 6 – Examples Non-compliance with these requirements jeopardises the correct functioning of the stove and the consequent loss of the warranty. Follow the instructions in the diagrams.
- Page 13 The stoves operate with the combustion chamber in a depressive state, so it is absolutely necessary to have a smoke evacuation duct that extracts the combustion gases properly. Smoke duct material: The pipes to be installed shall be rigid, of stainless steel with a minimum thickness of 0,5 mm, with joints for the connection between the different sections and accessories.
-
Page 14: Fuel
5.4. Installation with chimney As shown in figure 8, the installation of the pellet stove brings the exhaust pipe (with Ø80 mm) directly to the chimney. If the chimney is too large, it is recommended to intubate the smoke outlet with a tube with a minimum internal diameter of 80 mm. Provide a "T"... -
Page 15: Use Of Pellet Stove
The use of different pellets reduces the efficiency of the pellet stove and leads to deficient combustion processes. As a recommendation always opt for certified pellets not forgetting that before buying large quantities you should always test a sample. The physico-chemical properties of pellets (in particular size, friction, density and chemical composition) may vary within certain tolerances and according to the manufacturer. -
Page 16: Remote
It should be checked that there is sufficient air circulation in the room where the installation is carried out, otherwise the equipment will not work properly. For this reason, it should be noted that there are other heating equipment that consumes air for its operation (e.g. -
Page 17: Display Overview
a) Key for switching between c) Key to start/stop the b) Menu access key and manual and automatic mode device and to reset the confirmation key (ok). and for exiting the menus errors (esc). d) Key to advance menus to the left, to e) Key to advance menus to the right and increase and decrease the ambient fan flow to increase and decrease the power of... -
Page 18: Date And Time
It is possible to vary the set point temperature from 5 to 40 ºC by pressing the "-" key. Mode “manu”: In this mode, the machine will work at the power selected with the "-" key, which may vary from 1 (minimum power) to 5 (maximum power). 8.3.2. -
Page 19: Chrono
Week day To set the day of the week press "set" and start flashing, press "+" or "-" to select the desired day, press "ok" to confirm value. Press the "+" key to move to the "time" menu.” MODE MENU <... - Page 20 To activate the Chronomode, press "set" and start flashing, press "+" or "-" to select "on" or "Off", press "ok" to confirm your choice. Press the "+" key to move to the "Load Profile" menu. There are 10 weekly settings predefined in the Chronograph (see annexes point 17) with the selection of this, runs the program from Monday to Friday and from Saturday to Sunday press "set"...
- Page 21 Press "set" again and when flashing, press "+" or "-" to select "on" or "Off". Press "ok" to confirm your choice. Press the "+" key to move to the "P1 H. Start" menu. MODE MENU <P1 Habilita > To select the start time in program P1, press "set" and start flashing, press "+" or "-" to select the desired time, press "ok"...
-
Page 22: Sleep (This Menu Only Appears When The Stove Is Running)
To select the days of the week on which we want the program P1 to work, press "set" and use the "-" and "+" keys to choose the day of the week. Press "set" and start flashing. Use the "-" and "+" keys to select the "On" or "Off" option. Press "ok" to confirm your choice. -
Page 23: Info
MODE MENU 22:00 SLEEP 8.3.5. Info In this menu the user can view some information about the stove. By clicking on "set" the "Card Code" menu appears. Software / motherboard firmware code. Pressing the "+" key displays the following menu "security code". Security software / firmware code. - Page 24 Parameter code. Press the "+" key to display the following menu "working hours". This menu indicates how many hours of work the stove has. MODE MENU < de Funcioname > This menu indicates how many hours of work the stove has since the last service. MODE MENU <...
-
Page 25: Settings Menu (Ex: Language)
Theoretical pellet consumption Smoh temperature. MODE MENU 18ºC < emperatura Fum > Time (in "on") of rotation of the worm screw. 8.3.6. Settings Menu (Ex: Language) To change the settings of the stove, press set , "Language menu" appears to select the language. - Page 26 Eco mode When we activate the "ECO" mode together with the Thermostat function, the stove runs at maximum power until the thermostat opens the contact (NO) and then runs at minimum power for a previously established time interval (Shutdown delay time: factory value: 20 minutes).
- Page 27 MODE MENU < Iluminação > Remote control This function activates or deactivates the remote control, when we want to work with ambient thermostat remotely. Press "set" and with the "+" and "-" keys to select the "on" or "off" mode, press "Ok" to confirm. Press the "+" key to go to the "temperature unit"...
- Page 28 - Pellet This function increases or decreases the quantity of pellets in the activation process and power by 25 %. Press "set" and start flashing, press "+" or "-" to increase or decrease (from -10 to +10), as desired. Each unit must be multiplied by 2.5 to obtain the correct percentage.
-
Page 29: Technical Menu
message is displayed. To stop, press "ok". Press the "+" key to go to the " Technical) menu”. The technical menu is not available to the end user. 8.3.7. Technical menu This feature allows the user to adjust the unit's different parameters. Pressing "set" displays the "password"... -
Page 30: Stop
The pellets are fed through the supply channel to the burning pot (combustion chamber), where they will be ignited using an igniter. This process may take 5 to 10 minutes, depending on whether the worm screw used to push through the pellets has been previously filled or not. - Page 31 VERY IMPORTANT: Before installing the display it is mandatory that the machine is turned off (Unplug the power socket). a) After unpacking the device, remove the upper cover of the device by applying a slight upward force, the cover is spring-loaded and no screws need to be removed. Figure 15 –...
-
Page 32: Refill The Pellet Tank
Refill the pellet tank Open the pellet tank cap at the top of the equipment by moving the tab at the top, pour the pellet bag into the tank, close the tank again (see Figure 18). Figure 18 – Refueling the pellet tank Maintenance 12.1. -
Page 33: Daily/Weekly Maintenance
12.2.1. Additional cleaning For each 600-800 Kg of pellets consumed, an additional cleaning must be made.. 12.2.2. Cleaning the fume passage K50 To perform this cleaning, you must remove the worktop (pull the worktop upwards, spring fit), the side covers and the lower front grille inside the door. To remove these parts it is necessary to remove some screws. -
Page 34: Cleaning The Fume Circuit K50
Lateral vacuum Figure 24 – Removal of the side cover and cleaning of the fume passage 12.2.3. Cleaning the fume circuit K50 To perform this cleaning it is necessary to remove the front vermiculite (refractory material) from the inside of the combustion chamber, remove it from the fittings that are in the smoke deflector, if necessary remove the side vermiculites. - Page 35 to remove dirt from inside the combustion chamber. Push the parts back in reverse order. Figure 25 – Removal of smoke circuit protection Figure 26 – Cleaning of combustion chamber If it is found that the extraction of fumes is not being carried out in the best conditions, we recommend cleaning the extractor by vacuuming its interior.
- Page 36 a) Remove the abutment next to the fume extractor. At the same time disconnect the temperature probe, the silicone tube and the connecting cables that are attached to the extractor. a) Pilar b) Probe c) Tube d) Conectors Figure 27 – Removal of the abutment and elements attached to the extractor b) Remove the screws that support the turbine from the extractor, remove the turbine from the extractor housing.
-
Page 37: Alarm / Failure / Recommendation List
WARNING! The maintenance task frequency depends on the quality of the pellets. Note: See the warning label and read the maintenance instructions in chapter 15 Alarm / Failure / Recommendation List Alarme Código Causa e Resolução - the worm drive channel is empty - restart the No flame or Maximum time 2400 s unit... - Page 38 - Anomalias Anomalies “Service” (Maintenance) Air sensor failure The door is open Air temperature probe failure Tabela 3 - lista of anomalies Important notice: A “service” warning on the display (maintenance due) indicates that the unit has exceeded 2100 operating hours. In this case, the client must perform the unit's maintenance procedure (following the instruction on the Technical Manual).
-
Page 39: Installing And Operating With The Remote Control
Installing and operating with the remote control - “programmable thermostat” (optional) The pellet stoves are produced as standard with the display control. Alternatively, the pellet stove can be used with a generic external control (chronothermostat), or another type of control as long as it is voltage-free contact. To connect the equipment to pellets remotely through a chronothermostat or thermostat must use the interface (Figure 31-b), it is a plate placed on the back of the stove (Figure 30). -
Page 40: Installation Instructions For The External Control Unit
In the case of the wireless remote control it is necessary to connect the two wires, as shown in the following Figure: Legenda de cores: CN – Gray N – Black C – Brown A - Blue Figure 32 – Connecting the wireless remote control In the case of the wired remote control it is necessary to connect the black and gray wires to the receiver as shown in the following Figure. - Page 41 b) Crimple the terminals of the cable that supplies the transmitter with 220V. c) Connect the wires to the ON/OFF contact connector (Figure 34-e); route the wires through the slot on the side of the equipment into the stove (34- f).; d) Mount the interface at the respective stove location and connect the plug of the external control (On/Off contact) to the "remote"...
- Page 42 e) Connect the interface cable to the electronic board on the communication plug (Servizi 5J). Figure 34 - Instalação do cronotermostato...
-
Page 43: Maintenance Plan And Log
Maintenance Plan and Log To ensure the proper operation of the unit, maintenance operations must be performed, as described in Chapter 11 of this Instruction Manual or in the Maintenance and Cleaning Guide (Chapter 15). There are specific maintenance tasks that must be performed by authorised technicians only. -
Page 47: Maintenance Guide Label
Maintenance Guide Label Figure 35 –Maintenance Guide Label Note: The safety warnings sticker label is attached from factory to the unit’s pellet lid, in the portuguese language. Attached to the manual you will find other language versions of the sticker labels (Spanish, English, French and Italian). -
Page 48: Electrical Diagram Of The Free Standing Fire Unit
Electrical Diagram of the Free-Standing Fire Unit Figure 36 – Electrical diagram K50 stove (Europa) Life Cycle of a Free-Standing Fire Unit Approximately 90% of the materials used to manufacture these units are recyclable, contributing towards a reduced environmental impact and a more sustainable planet. -
Page 49: Guarantee
(model and serial number). 3. Product warranty terms 3.1 Solzaima, S.A., responds to the Buyer, for the lack of conformity of the Product with the respective contract of sale, within the following periods: 3.1.1 A period of 24 months from the date of delivery of the good, in the case of domestic use of the product, save the provisions of the following number regarding the intensive use;... - Page 50 In order to exercise its rights, and provided that the term indicated in 3.1 is not exceeded, the Buyer must report in writing to Solzaima, S.A., the lack of conformity of the Product within a maximum period of: 3.5.1 60 (sixty) days after the date on which it has detected it in the case of...
- Page 51 electricity and / or other related to the equipment or sector and as described in the instruction manual. A product installation that does not conform to the manufacturer's specifications and / or does not comply with the legal regulations on this subject will not give rise to the application of this Warranty.
- Page 52 the equipment; there shall be no cut-off valve between the equipment and its safety valve; provision should be made for a systematic preventive maintenance plan to attest to the correct functioning of the said safety features; irrespective of the type of appliance, all safety valves shall be channeled to drained sewage to prevent damage to the dwelling by water discharges.
- Page 53 3.17 The Warranty is valid for the Products and equipment sold by Solzaima SA solely and exclusively within the geographical and territorial zone of the country where the Product was sold by Solzaima. 4. Circumstances that exclude the application of the Warranty...
- Page 54 4.8. Defects caused by the use of accessories or replacement components other than those determined by Solzaima, S.A.; 4.9. Defects arising from non-compliance with the installation, use and operation instructions or applications not conforming to the intended use of the Product, or from abnormal climatic factors, unusual operating conditions, overload or maintenance or cleaning performed improperly;...
- Page 55 4.16. The installation of the equipment supplied by Solzaima, S.A. should contemplate the possibility of their easy removal, as well as points of access to the mechanical, hydraulic and electronic components of the equipment and the installation.
- Page 56 From the moment they are removed from the equipment, the Parts used are considered as waste. Solzaima as a producer of waste in the scope of its activity is obliged by the legislation in force to deliver them to a licensed entity that performs the proper waste management operations under the law and therefore is prevented from giving them another destination, whatever.
- Page 57 11. Administrative expenses In the case of invoices for services rendered, they are not processed in any stipulated period with default interest at the maximum legal rate in force. 12. Competent court For the resolution of any dispute arising from the purchase and sale agreement having as object the products covered by the warranty, the contracting parties attribute exclusive jurisdiction to the courts of the district of Águeda, with express waiver of any other.
-
Page 58: Annex
Annex 20.1. Weekly programming of the chrono Programacão horaria Nº Prog Dias Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Seg-Sex Sab-Dom Note: the stove is active in the filled squares and deactivates in the blank squares. -
Page 59: Fluxograme
20.2. Fluxograme Ignition... -
Page 61: Declaration Of Performence
Shutdown 20.3. Declaration of performence... - Page 62 ECLARAÇÃO DE ESEMPENHO ECLARACIÓN RESTACIONES ECLARATION OF ERFORMANCE ÉCLARATION DE ERFORMANCE DD-046 º Código de identificação único do produto-tipo | Código de identificación único del tipo de producto | Unique identification code of the product type | Le code d'identification unique du type de produit | Codice unico di identificazione del tipo di prodotto –...
- Page 63 Desempenho declarado | Desempeño declarado | Declared performance | Performance déclarée | Dichiarazione di prestazione Especificações técnicas Características essenciais | harmonizadas | Especificaciones Características esenciales | técnicas armonizadas | Desempenho | Desempeño | Essencial characteristics | Harmonized technical Performance | Prestazione Caractéristiques essentielles specifications | Spécifications | Caratteristiche essenziali...
- Page 64 placed a load support | tous les 10 m de conduit de fumée doit être placé un support de charge | ogni 10 m della canna fumaria deve essere posto un supporto di carico De acordo com os requisitos | De Potência térmica Potencia...
