INSYS GPRS mini
If you are doubt, please
 Use the mains power adapter that is provided by your distributor and
is know to work properly with your modem
 Make sure that your signal and system design is according to the
above
 Consult our support team that will be more than happy to assist you.
5.2

Switching OFF the modem

There are two ways to switch off (power down) the modem as described be-
low:
use the "AT^SMSO" command
EMERG_OFF to high level for t < 1s
A delay of up to 10s is experienced as the modem logs off the network
5.3

Operating states / LEDs

5.3.1 Power up LED (green LED in the middle)

The modem has a green power up LED, as depicted below, which is used to
indicate various operating states. These states are described in following ta-
ble.
Operating state of INSYS GPRS mini
Device off
net search / not registered /
registered full service
A call is active
Power up LED state
Permanently off
Fast blinking
Slow blinking
Permanently on
Operation
23
