Mechanical Description
3
Mechanical Description
3.1
Overview
The pictures below show the mechanical design of the INSYS GPRS mini
along with the positions of the different connectors and mounting holes. The
INSYS GPRS mini case is made of durable PC/ABS plastic.
Access to
SIM card
holder
1 status
LED
FME antenna
connector
14
USB 2.0 port
mounting
holes
Power connector
RS232 con-
nector
INSYS GPRS mini
