INSYS GPRS mini
4.8
Mini USB Connector
The modem supports a standard USB 2.0 Full Speed slave interface for AT-
commands. The maximum baud rate to communicate with the INSYS GPRS
mini is up to 12Mbit/s.
Drivers for several operating systems (e.g. Windows Vista, Windows XP or
Linux) are available through the INSYS icom support team (support@insys-
tec.de).
INSYS GPRS mini Pin Layout for Mini USB connector:
Pin
1
2
3
4
5
Signal
VUSB
D -
D +
not connected
GND
Pin 5
Pin 1
Electrical Description
21
