Electrical Description
4.2
Antenna Connector
The antenna connector allows transmission of radio frequency (RF) signals
between the modem and an external customer-supplied antenna. The mo-
dem is fitted with a 50Ω, FME male coaxial jack.
Output Power:
2 Watt Peak (Class 4)
1 Watt Peak (Class 1)
Description of recommended antenna parameters:
The antenna that the customer chooses to use should fulfil the following re-
quirements:
Frequency range
Bandwidth
Gain
Impedance
Input power
VSWR recommended
4.3
SIM card reader
The INSYS GPRS mini is fitted with a SIM card reader designed for 1.8V and
for 3V SIM cards. It is the flip-up type which is lockable in the horizontal po-
sition and is accessed through a removable panel.
18
GSM 900/850 MHz
GSM 1800/1900 MHz
GSM 850/900 MHz
GSM 1800/1900 MHz
80 MHz in EGSM 900, 70 MHz if GSM 850,
< 3dBi
50 ohm
> 33dBm (2W) peak power in GSM
< 2
INSYS GPRS mini
