Kikusui HP01A-TOS Operation Manual

Operation Manual
High Voltage Test Probe
This product is a probe used by connecting to a Kikusui TOS series withstanding volt-
age tester or a TOS93 series electrical safety analyzer (hereafter referred to as the
tester). It used to generate test voltages. Its convenient shape allows faster connec-
tion to the device under test (DUT).
To prevent potential electric shocks while performing tasks close to a high-voltage
1
area such as the DUT, always wear rubber gloves for electrical work when perform-
ing withstand voltage tests with the test probe.
This product is designed to be used in combination with a Kikusui tester.
Carefully read the warnings and precautions given in the Tester Operation
Manual before attempting to use it.

Safety Precautions

Indicates an imminently hazardous situation which, if ignored,
DANGER
will result in death or serious injury.
Indicates a potentially hazardous situation which, if ignored,
WARNING
could result in death or serious injury.
Indicates a potentially hazardous situation which, if ignored, may
CAUTION
result in slight injury or damage to the product or other property.
To prevent electric shock that may result in serious injury or death, never
touch the following items:
• Never touch the contact pin of the test probe.
• Never touch the DUT during testing.
Observe the following instructions to minimize the potential for electric shock
that may result in serious injury or death.
• Never perform testing when leaning on your elbows at the test bench or in other areas.
• Do not fasten the slide lever of the test probe such that the contact pin is exposed.
• Keep the probe cables neat and free of tangles. Never drape the high voltage
cable over any part of your body.
• Generate test voltages only when performing actual tests.
• Operate the product without wearing rubber gloves for electrical work.
Part No. Z1-000-652, IA000787
Dec 2018
HP01A-TOS HP02A-TOS
DANGER
WARNING
