1.3M MIPI
STC-S133MIP Color CMOS Cameras
STC-S133MIP-NF
STC-S133MIP
STC-S133MIP-L
STC-S133MIP-CS
STC-S133MIP-D
STC-S133MIP-DL
STC-S133MIP-DCS
STC-S133MIP-ALL
STC-S133MIP-ALCS
STC-S133MIP-DALL
STC-S133MIP-DALCS
Product Specifications and User's Guide
STC-S133MIP
Product Specifications and User's Guide
(1.3M / No lens mount / No IR Cut Filter / Board)
(1.3M / No lens mount / IR Cut Filter / Board)
(1.3M / M12 lens mount / IR Cut Filter / Board)
(1.3M / CS mount / IR Cut Filter / Board)
(1.3M / No lens mount / Dual Pass Filter / Board)
(1.3M / M12 lens mount / Dual Pass Filter / Board)
(1.3M / CS mount / Dual Pass Filter / Board)
(1.3M / M12 lens mount / IR Cut Filter / Cased)
(1.3M / CS mount / IR Cut Filter / Cased)
(1.3M / M12 lens mount / Dual Pass Filter / Cased)
(1.3M / CS mount / Dual Pass Filter / Cased)
No.17S023-02
1/64
Advertisement
Table of Contents
Related Manuals for Omron STC-S133MIP Series
Summary of Contents for Omron STC-S133MIP Series
- Page 1 No.17S023-02 1.3M MIPI STC-S133MIP Color CMOS Cameras STC-S133MIP-NF (1.3M / No lens mount / No IR Cut Filter / Board) STC-S133MIP (1.3M / No lens mount / IR Cut Filter / Board) STC-S133MIP-L (1.3M / M12 lens mount / IR Cut Filter / Board) STC-S133MIP-CS (1.3M / CS mount / IR Cut Filter / Board) STC-S133MIP-D...
-
Page 2: Table Of Contents
No.17S023-02 Table of Contents Product Precautions ..................7 Warranty ......................7 Introduction ......................8 Features ............................ 8 Product Number Naming Method ................... 8 Specifications ....................9 Electronic specifications ......................9 Spectral Sensitivity Characteristics ..................11 CMOS Sensor Spectral Sensitivity Characteristics ............... 11 IR Cut Filter Spectral Sensitivity Characteristics (STC-S133MIP / STC-S133MIP-L / STC-S133MIP-CS / STC-S133MIP-ALL / STC-S133MIP-ALCS) ............ - Page 3 No.17S023-02 STC-S133MIP-ALL / STC-S133MIP-DALL ................21 STC-S133MIP-ALCS / STC-S133MIP-DALCS ................ 22 User’s guide for communication software ............. 23 Environmental software and tools ..................23 Connection configuration ...................... 23 Communication method ......................23 Connectors ..........................24 Setting of Raspberry Pi ......................24 Basic operating procedure ....................
- Page 4 No.17S023-02 OSD operation by camera control software ................. 52 OSD menu ............................53 SETUP MENU ................................53 SHUTTER/AGC ................................54 WHITE BAL .................................. 55 PICT ADJUST ................................57 DEFOG..................................58 WDR/ATR ..................................59 Day/Night ..................................60 DNR....................................60 PRIVACY ..................................61 LANGUAGE .................................
- Page 5 No.17S023-02 Precautions for safe use Please read carefully this “Precautions for safe use” before use the camera. Then the camera uses correctly with agreeing with below notes. In this “Precautions for safe use”, notes divides into “Warning” and “Caution” to use the camera safety and prevent to harm and damage.
- Page 6 No.17S023-02 Caution Do not grounding DC power (+) of all devices It is necessary to wiring and mounting that is that are connect to the camera. specified in the specifications for this camera. The camera housing is connecting to 0 V line of This will cause of fire or malfunction.
-
Page 7: Product Precautions
No.17S023-02 Product Precautions Do not give shock to the camera. Do not haul or damage the camera cable. Do not wrap the camera with any material while using the camera. This will cause the internal camera temperature to increase. ... -
Page 8: Introduction
No.17S023-02 Introduction This document describes the specifications of the following cameras STC-S133MIP-NF / STC-S133MIP / STC-S133MIP-L / STC-S133MIP-CS (IR Cut Filter, Board models) STC-S133MIP-D / STC-S133MIP-DL / STC-S133MIP-DCS (Dual Pass Filter, Board models) STC-S133MIP -ALL / STC-S133MIP-ALCS (IR Cut Filter, Cased models) STC-S133MIP-DALL / STC-S133MIP-DALCS (Dual Pass Filter, Cased models) Features... -
Page 9: Specifications
No.17S023-02 Specifications Electronic specifications Model Number STC-S133MIP-NF / STC-S133MIP / STC-S133MIP-L / STC-S133MIP-CS / STC-S133MIP-D / STC-S133MIP-DL / STC-S133MIP-DCS / STC-S133MIP-ALL / STC-S133MIP-ALCS / STC-S133MIP-DALL / STC-S133MIP-DALCS Image sensor 1/3.2" 1.27M Progressive CMOS (SONY ISX017) Video signal format 1,280 (H) x 720 (V) 60 / 50 / 30 / 25 fps, 1,280 (H) x 960 (V) 60 / 30 / 25 fps (Default: 1,280 (H) x 720 (V) 60 fps) Chip size 9.5 (H) x 8.7 (V) mm... - Page 10 No.17S023-02 Precautions (*1) The sensitivity is measuring the luminance when white level achieved 100 % in below conditions. Camera Setting Environment Parameter Setting Parameter Setting Gain Up 0 dB Light Source Light Box (White) Color temperature 5,100K White Balance Optimum Lens Electrical Shutter 1/30 seconds...
-
Page 11: Spectral Sensitivity Characteristics
No.17S023-02 Spectral Sensitivity Characteristics CMOS Sensor Spectral Sensitivity Characteristics STC-S133MIP 11/64 Product Specifications and User’s Guide... -
Page 12: Ir Cut Filter Spectral Sensitivity Characteristics (Stc-S133Mip / Stc-S133Mip-L / Stc-S133Mip-Cs / Stc-S133Mip-All / Stc-S133Mip-Alcs)
No.17S023-02 IR Cut Filter Spectral Sensitivity Characteristics (STC-S133MIP / STC-S133MIP-L / STC-S133MIP-CS / STC-S133MIP-ALL / STC-S133MIP-ALCS) Dual Pass Filter Spectral Sensitivity Characteristics (STC-S133MIP-D / STC-S133MIP-DL / STC-S133MIP-DCS / STC-S133MIP-DALL / STC-S133MIP-DALCS) Transmittance (%) 1050 1150 STC-S133MIP 12/64 Product Specifications and User’s Guide... -
Page 13: Mechanical Specifications
No.17S023-02 Mechanical Specifications STC-S133MIP-NF Model Number STC-S133MIP-NF Dimensions (*1) φ22 x 19 (H) x 1.3 (D) mm Optical Filter IR Cut Filter Interface FFC cable: 15 pin 1.0 mm pitch (Morex: 52808-1571) Lens Mount No lens mount Camera Mounting φ2.3 TH (Two) Cable length for attached FFC cable 150 mm Weight... -
Page 14: Stc-S133Mip-Cs / Stc-S133Mip-Dcs
No.17S023-02 STC-S133MIP-CS / STC-S133MIP-DCS Model Number STC-S133MIP-CS STC-S133MIP-DCS Dimensions (*1) φ28 x 14.8 (D) m Optical Filter IR Cut Filter built in Dual Pass Filter built in Interface FFC cable: 15 pin 1.0 mm pitch (Morex: 52808-1571) Lens Mount CS lens mount Camera Mounting M2 screw holes (Tow on Top and bottom plate) Cable length for attached FFC cable... -
Page 15: Connector Specifications
No.17S023-02 Connector specifications Bottom of camera Power / MIPI output / Communication CN1 connector: 52808-1571 (Morex) Pin assignment Signal Name Signal POWER Power In (+3.3 to +5 V) I2C Data I2C Clock MIPI Positive Clock MIPI Negative Clock MIPI Data 2 Positive MIPI Data 2 Negative MIPI Data 1 Positive MIPI Data 1 Negative... -
Page 16: Mipi Output Specifications
No.17S023-02 MIPI Output Specifications Data Type: 0x1E (YUV422 8bits) The YCbCr output image for MIPI output is showing in below. YCbCr data is output as order of Cb, Y, Cr, Y. Data Type of Packet Header is 0x1E (YUV422 8bits) YCbCr data is output after Frame Start Packet is output. -
Page 17: Dimensions
No.17S023-02 Dimensions STC-S133MIP-NF 0.72 φ 22.4 Image 2-φ 2.3 NTH Conductor Reinforcing plate 2-R2.25 GND (6.3) Unit: mm STC-S133MIP 17/64 Product Specifications and User’s Guide... -
Page 18: Stc-S133Mip / Stc-S133Mip-D
No.17S023-02 STC-S133MIP / STC-S133MIP-D 2-M2 Depth2.5 (Top and bottom) φ 23 Image Conductor Reinforcing plate Optical Filter 4-M2 Depth2.5 4.87 (in Air) (12.3) Unit: mm STC-S133MIP 18/64 Product Specifications and User’s Guide... -
Page 19: Stc-S133Mip-L / Stc-S133Mip-Dl
No.17S023-02 5.3 STC-S133MIP-L / STC-S133MIP-DL 2-M3 Depth3.0 (Top and bottom) 15.27 (in Air) φ 25 Image Conductor Reinforcing plate M12xP0.5 (14.3) 4-M2 Depth3.0 Optical Filter Unit: mm STC-S133MIP 19/64 Product Specifications and User’s Guide... -
Page 20: Stc-S133Mip-Cs / Stc-S133Mip-Dcs
No.17S023-02 STC-S133MIP-CS / STC-S133MIP-DCS 2-M2 Depth3.0 (Top and bottom) 14.8 13.6 CS mount φ 23 Conductor Reinforcing plate Optical Filter (19.9) Unit: mm STC-S133MIP 20/64 Product Specifications and User’s Guide... -
Page 21: Stc-S133Mip-All / Stc-S133Mip-Dall
No.17S023-02 STC-S133MIP-ALL / STC-S133MIP-DALL 14.4 10.4 M12xP0.5 Reinforcing plate 15.27 (in Air) Image Optical Filter Both sides are same 2-M2.5 Depth3.0 (Top, bottom and both sides) Unit: mm STC-S133MIP 21/64 Product Specifications and User’s Guide... -
Page 22: Stc-S133Mip-Alcs / Stc-S133Mip-Dalcs
No.17S023-02 STC-S133MIP-ALCS / STC-S133MIP-DALCS 21.9 10.3 CS Mount 14.4 Reinforcing plate Optical Filter Both sides are same 2-M2.5 Depth3.0 (Top, bottom and both sides) Unit: mm STC-S133MIP 22/64 Product Specifications and User’s Guide... -
Page 23: User's Guide For Communication Software
No.17S023-02 User’s guide for communication software The settings of STC-S133MPI camera can be change by below methods: Camera setting changes directly through I2C. (Please refer “STC-S133 Series Protocol Specifications” for communicating to camera.) Camera setting change from Windows PC through Raspberry Pi. (Please refer below procedure.) Environmental software and tools Camera communication software: KSACtrl v2.03 or newer... -
Page 24: Connectors
No.17S023-02 Connectors Connection between STC-S133MIP and Raspberry Pi 15pin FFC (1.0 mm pitch) connects to CN1 connector on STC-S133MPI and J3 connector on Raspberry Pi Model 3 STC-S133MIP CN1 Raspberry Pi Model 3 J3 Name Name POWER SDA0 SCL0 CAM_GPIO1 CAM_GPIO0 CAM1_CP CAM1_CN... -
Page 25: Basic Operating Procedure
No.17S023-02 Basic operating procedure The camera communication software (KSACtrl) use UART communication. It is necessary to setup Raspberry Pi to use UART from / to I2C conversion. The camera communication software (KSACtrl) is usable after install KSACtrl software. Start KSACtrl software. Select the COM port number to use the camera communication by selecting “Port Setting”... -
Page 26: The Descriptions For The Buttons
No.17S023-02 The descriptions for the buttons Read All Read out all camera settings in the camera. Please select this button every time when the camera power is turning on. This software stores as the camera default settings in to the Flash memory on the camera when first time select “Read All”... -
Page 27: The Descriptions Of The Functions
No.17S023-02 The descriptions of the functions Menue File(F) Save As[DSP->File]… Read the camera settings and creates the camera settings file. Open[File->DSP]… Load the camera settings from the camera settings file then apply to the camera. Open[File->Flash]… Load the camera settings from the camera settings file then apply to the camera and save the camera settings in to the flash memory. -
Page 28: Shutter/Gain Tab
No.17S023-02 Shutter/Gain Tab Exposure Control Mode (Default: AE) The brightness level is adjusting with the shutter and gain automatically. It is necessary to set the shutter and the gain at “Normal AE” Tab. HOLD The shutter and gain are holding. When the brightness of the target is changed, the camera does not adjust the brightness. Scale ME The brightness level is adjusting by the shutter and gain settings. - Page 29 No.17S023-02 Minimum / Maximum shutter time, Minimum / Maximum Gain Set the limit for the shutter and gain. Shutter Priority time The AE becomes the shutter prioritized AE when setting other than “0” while AE mode. It is necessary to select the value that between the minimum and maximum shutter time. The shutter is fixed as the selected shutter time and the brightness level is adjusting by the gain.
- Page 30 No.17S023-02 Flicker-less AE Mode (Default: Auto) Auto When the power on the camera with auto flicker-less, the default: condition is “OFF” and the function does not work unless detecting the flicker. The shutter time is adjusting continuously when the flicker less function starting. The flicker-less function is Off when the brightness of image becoming bright from 1/100seconds or 1/120 seconds condition, or the flicker less reset function is 50Hz / 60Hz Forced This mode forces to 50Hz/60Hz flicker less function even does not detect the flicker.
-
Page 31: Lens Tab
No.17S023-02 Lens Tab The lens compensation settings are selectable in this Tab. Vignetting and distortion Select “Enable” or “Disable” for the vignetting compensation and distortion compensation functions. Please select “Enable” if the vignetting or distortion compensation function uses. (Default: Disable) Vignetting compensation Select “Enable”... - Page 32 No.17S023-02 Distortion compensation settings KNOT K0 (optical center) to KNOT K13 (edge) are the compensation points for the distortion compensation. When set the greater value, the distortion is reduced. When set the smaller value, the distortion is extended. There are four types (A, B, C and D) of the compensation points are available. Distortion compensation OFF Distortion compensation ON STC-S133MIP...
-
Page 33: Osd Tab
No.17S023-02 OSD Tab OSD settings are selectable in this Tab. OSD is available when the resolution is 1,280 x 720 or 1,280 x 900. The OSD is usable with “Up”, “Down”, “Left”, “Right” and “Enter” buttons. Save button Save the OSD horizontal and vertical start position for the OSD parameter load is valid. Note. - Page 34 No.17S023-02 Cursor, character and character edge settings Cursor blend ratio / Character blend ratio Set the transparent ratio for the cursor and character of the OSD. Cursor Brightness / Character Brightness Set the brightness for the cursor and character of the OSD. Cursor Cb / Cursor Cr / Character Cb / Character Cr Set the color (Cb and Cr) for cursor and character of the OSD.
-
Page 35: Wdr Tab
No.17S023-02 WDR Tab The image is composed with two or three different shutter time images to compensate the clipped white image and crushed shadow image. Wide Dynamic Range (Default: Auto) Auto: WDR exposure and long exposure switch automatically for the object condition. WDR fixed when select “Long exposure fixed”... - Page 36 No.17S023-02 High Luminance Compensation (HLC) The high luminance compensation function is improved the visibility for the license plate under the dark condition with the strong light (like headlights), with suppression and mask process. H-luminance threshold ON-OFF Set the threshold for high luminance compensation from ON to OFF H-luminance threshold OFF-ON Set the threshold for high luminance compensation from OFF to ON L-luminance threshold ON-OFF...
-
Page 37: Ae Weight Tab
No.17S023-02 AE Weight Tab Photometry mode It is possible to keep the brightness level or the specific image are by adjusting the weight of the histogram for the area or the brightness. The photometry mode is selectable from “Average”, “Center”, “Spot” and “Histogram”. The average brightness of the full image uses for the average photometry mode. -
Page 38: Normal Ae Tab
No.17S023-02 Normal AE Tab Set the shutter and gain for the normal AE mode. 5 steps control rage for the shutter and gain is selectable for Normal AE. Please set from 1 (Bright) to 5 (Dark). Please set with the monotonous inclement. The default settings for the shutter and gain for 5 steps control are in below table. -
Page 39: Full Me Tab
No.17S023-02 Full ME Tab Set the shutter and gain for the full ME AE mode. Set the shutter speed and gain for the long exposure, short exposure 1 and short exposure 2. STC-S133MIP 39/64 Product Specifications and User’s Guide... -
Page 40: Ae Mask Tab
No.17S023-02 AE Mask Tab Set the mask frame for AE frame detection. Set mask frame is excluding frame for AE detection. The mask frame can set up to 16 frames. In case of the image has vignetting, the optimized brightness of the image can keep it by excluding the vignetting area for AE detection. -
Page 41: Whitebalance Tab
No.17S023-02 WhiteBalance Tab Push lock pin White balance mode ATW mode The white balance control automatically with the indoor/outdoor judgement and estimate the light source. ATW mode is less inference for the color saturated target. All pull in mode The white balance control automatically without dependence of the indoor/outdoor light source. The wide rage color pull into the white. - Page 42 No.17S023-02 White balance offset This function is shifting the convergence point by adding the offset. This function is useful when keep the color. User mode Five different use modes are available. The default setting for five user modes are in below table. User mode0 Fine weather (shade) 5,800 K...
-
Page 43: Gamma Tab
No.17S023-02 Gamma Tab Gamma offset Add the offset for the gamma curve. When set the greater offset, the output for the preset point become smaller. Gamma through Set the through or magnification for the input data. Gamma preset (manual gamma) 27 points adjustment is available for the manual gamma. -
Page 44: Chroma Tab
No.17S023-02 Chroma Tab Hue adjustment Hue is the center adjustment position when set 0[h]. When set 1[h] to 5A[h], the hue changes with the clockwise rotation. When set FF[h] to A6[h], the hue changes with the counter clockwise rotation. The unit is 1deg. / step. Saturation adjustment Saturation is the center adjustment position when set 80[h]. -
Page 45: Other Tab
No.17S023-02 Other Tab UART Changed baud rate is enabled when restart the camera after save the baud rate setting to the flash memory on the camera by selecting “DSP->FLASH” button. Mirror/Flip Set the image output with the horizontal flip, vertical flip or horizontal and vertical flip. Sharpness / Contrast / Brightness / Negative-positive Adjust each setting for the image. -
Page 46: Privacy Mask Tab
No.17S023-02 Privacy Mask Tab Set the privacy mask setting. Up to 16 frames are available. Mosaicing horizontal width / vertical width Set the mosaicing width when the mosicing mask is enabled. The unit for the horizontal width is an even number of the pixels and the 1 line for the vertical width. Mask x Select On/Off for the mask. - Page 47 No.17S023-02 Mask * Gate When set on this, the masking area is excluding from the AE detection. Note) The smaller mask number has the priority for mask display. STC-S133MIP 47/64 Product Specifications and User’s Guide...
-
Page 48: Day&Night Tab
No.17S023-02 Day&Night Tab Set the Day & Night function. Day&Night The camera switches automatically based on AE status when set “AUTO” Manual Mode Day or Night mode is selectable when selecting “MANUAL” at Day&Night. Counter unit Select the unit of the judgement time (frame or second) Day/Night Threshold dark side / threshold light side Set the threshold for the auto Day/Night. -
Page 49: Aperture Tab
No.17S023-02 Aperture Tab Set the enhancement settings for the edge of the image. Set the horizontal, vertical and oblique aperture gain for 1/2fs (high frequency) and 1/4fs (low frequency). When setting 40[h], enhancement gain is x1. Analog Tab MIP Tab Selects the output image format (resolution and frame rate). -
Page 50: Blemish Pixel Tab
No.17S023-02 Blemish Pixel Tab When selecting “Auto Detect” button, the white pixel compensates automatically. It is necessary to shade the camera before using this function. Note If the auto detects fails due to the too bright (not shading the camera), saved compensated values are cleared. Info. -
Page 51: One Shot
No.17S023-02 One Shot One shot mode is selectable by “OneShot” under “Mode” in the menu. Save or load the settings by the function group. Read DSP Read DSP data form the camera and make setting file. Write FALSH Write selected setting file into camera’s DSP, and load to Flash and verify. Verify Verify DSP register value to setting file. -
Page 52: Camera Setting By The Osd
No.17S023-02 Camera setting by the OSD This camera can change the camera settings by the On Screen Display with camera control software (S133Control). OSD operation by camera control software A. Please check the 4-6. OSD tab descriptions for details of the operation. Note. -
Page 53: Osd Menu
No.17S023-02 OSD menu SETUP MENU Page 1 SHUTTER/AGC Shutter/ Gain Setting (Default: AUTO) WHITE BAL White Balance Setting (Default: ATW) BACKLIGHT Back Light Compensation (Default: OFF) PICT ADJUST Image Processing Setting DEFOG Defog Function (Default: OFF) WDR/ATR WDR/ATR Setting (Default: WDR and ATR ON) Page 2 DAT/NIGHT Day Night Setting (Default: AUTO fixed) -
Page 54: Shutter/Agc
No.17S023-02 SHUTTER/AGC 1) AUTO SETUP Setup the AE (Auto Exposure) settings When selecting “ENTER” after select “AUTO” at “SHUTTER/AGC”, AE settings are selectable. HIGH LUMINANCE MODE SHUT Fixed shutter AE LEVEL Set the target brightness level for AE (Default:56) LOW LUMINANCE Select AGC mode (ON/OFF) (Default: ON) AE LEVEL Set the target brightness level for AE (AGC) (Default: X1.00) -
Page 55: White Bal
No.17S023-02 WHITE BAL ATW Auto White balance mode When selecting “ENTER” after select “AUTO” at “WHITE BAL”, ATW settings are selectable. SPEED Set pull in speed for ATW (Default: 128) DELAY CNT Set delay time for ATW (Default: 8) ATW FRAME Select pull in frame for INDOOR/OUTDOOR ENVIRONMENT Select pull in frame for ATW (Default: INDOOR) - Page 56 No.17S023-02 MANUAL Manual White balance mode When selecting “ENTER” after select “MANUAL” at “WHITE BAL”, the color temperature for the manual white balance is adjustable. PUSH LOCK Push to set White Balance BACK LIGHT Back light compensation is OFF Back light compensation is ON HLC (High Luminance Compensation) is enabled STC-S133MIP 56/64...
-
Page 57: Pict Adjust
No.17S023-02 PICT ADJUST When selecting “ENTER” after select “PICT ADJUST”, image processing settings are selectable. FLIP Normal image H-FLIP Horizontal flip image V-FLIP Vertical flip image HV-FLIP Horizontal and vertical flip image BRIGHTNESS Set the brightness of the image (Default: 128) CONTRAST Set the contrast of the image (Default: 128) SHARPNESS... -
Page 58: Defog
No.17S023-02 DEFOG Default: OFF When selecting “ENTER” after select “ON” at “DEFOG”, defog setting is selectable. LEVEL Set the defog level and sensitivity Middle HIGH High STC-S133MIP 58/64 Product Specifications and User’s Guide... -
Page 59: Wdr/Atr
No.17S023-02 WDR/ATR Set WDR and ATR function OFF When selecting “ENTER” after select “ATR” at “WDR/ATR”, ATR settings are selectable. BRIGHTNESS Set the brightness highlight level Middle(Default:) HIGH High CONTRAST Set the contrast highlight level Middle HIGH High When selecting “ENTER” after select “WDR” at “WDR/ATR”, WDR settings are selectable. BRIGHTNESS Set the brightness compression level Middle... -
Page 60: Day/Night
No.17S023-02 Day/Night AUTO (Default DELAY CNT Transition time between Day / Night (Default: 5) DAY->NIGHT Threshold for switch from Day to Night (Default: 90) NIGHT->DAY Threshold for switch from Night to Day (Default: 110) Set the noise reduction settings When selecting “ENTER” after select “ON” at “DNR”, noise reduction settings are selectable. MODE Noise reduction is OFF Y/C Filter is ON (Default:) -
Page 61: Privacy
No.17S023-02 PRIVACY Set the privacy mask settings When selecting “ENTER” after select “ON” at “PRIVACY”, privacy mask settings are selectable. AREA SEL Select the privacy mask frame TOP, BOTTOM, LEFT, RIGHT Set the privacy mask position (Default: 0) COLOR Se the color for the privacy mask (Default: 1) TANSP (0.00 / 050 / 0.75 / 1.00) Set the transparent level for the privacy mask Default: 0.00) MOSAIC OFF Mosaic is OFF(Default:) -
Page 62: Language
No.17S023-02 LANGUAGE Select the language for the OSD menu from English, Douche, French, Russian, Portuguese or Spanish. CAMERA RESET Initialize all OSD settings SAVE ALL When selecting “SAVE ALL” after select “EXIT”, save all OSD settings to the flash memory on the camera. It is necessary to enable “OSD parameter Load”... -
Page 63: Revisions History
No.17S023-02 Revisions History Date Changes Note 2018/09/19 New document 2018/09/26 Revised Added Cased models. 2019/05/14 Revised Revised connector pin assignment Note Product specifications would be modified without notification. Company names and product names in this document are trademarks of their respective owners. STC-S133MIP 63/64 Product Specifications and User’s Guide... - Page 64 No.17S023-02 19F, Ebina Prime Tower 9-50, Chuo 2 chome Ebina-city, Kanagawa 243-0432 Japan TEL 81-46-236-6660 FAX 81-46-236-6661 URL http://www.sentech.co.jp/ STC-S133MIP 64/64 Product Specifications and User’s Guide...
