Omron Sentech STC-CMC120APCL Series Product Specifications And User's Manual

Omron Sentech STC-CMC120APCL Series Product Specifications And User's Manual

12 meg cmos color / monochrome camera link camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

12 Meg CMOS Color / Monochrome
Camera Link Camera
STC-CMC120APCL (12M Color)
STC-CMB120APCL (12M Monochrome)
Product Specifications and Users guide
STC-CMC120APCL, STC-CMB120APCL
Specifications and Users guide
For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com
No.14S056-11
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sentech STC-CMC120APCL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron Sentech STC-CMC120APCL Series

Summary of Contents for Omron Sentech STC-CMC120APCL Series

  • Page 1 No.14S056-11 12 Meg CMOS Color / Monochrome Camera Link Camera STC-CMC120APCL (12M Color) STC-CMB120APCL (12M Monochrome) Product Specifications and Users guide STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...

  • Page 2: Table Of Contents

    No.14S056-11 Table of Contents OVERVIEW ..................................5 ..................................5 EATURES ................................5 AMING ETHOD SPECIFICATIONS ................................. 6 ......6 LECTRONIC SPECIFICATIONS ECHANICAL SPECIFICATIONS NVIRONMENTAL SPECIFICATIONS 2.1.1 STC- CMC120APCL (Color) / STC- CMB120APCL (Monochrome) ..............6 ........................7 PECTRAL ENSITIVITY HARACTERISTICS 2.2.1 STC-CMC120APCL/ STC-CMB120APCL ......................
  • Page 3 No.14S056-11 CONTROL SOFTWARE ............................... 54 ..................................54 UMMARY 8.1.1 File ..................................55 8.1.2 Comm ..................................55 8.1.3 Mode ..................................55 8.1.4 Help ..................................56 ) ..........................56 OFTWARE UNCTION TANDARD 8.2.1 Shutter .................................. 56 8.2.2 Mode ..................................57 8.2.3 Gain ..................................58 8.2.4 Serial Communication ............................
  • Page 4 No.14S056-11 Product Precautions Handle the camera with care. Do not abuse the camera. Avoid striking or shaking it. Improper handling or storage  could damage the camera. Do not pull or damage the camera cable.  During camera use, do not wrap the unit in any material. This will cause the internal temperature of the unit to ...

  • Page 5: Overview

    No.14S056-11 Overview This document describes the specifications of the following cameras: STC-CMC120APCL (12M Color) STC-CMB120APCL (12M Monochrome) 1.1 Features  12M pixel (4096 x 3072)  CMOS Sensor (Global Shutter)  Camera Link (Deca, Full, Medium, Base Configuration)  10,8,4,3,2TAP ...

  • Page 6: Specifications

    No.14S056-11 Specifications 2.1 Electronic specifications / Mechanical specifications / Environmental specifications 2.1.1 STC- CMC120APCL (Color) / STC- CMB120APCL (Monochrome) Table 1. Specifications STC-CMC120APCL Product STC-CMB120PCL 1.76 “ Type 12Meg color progressive CMOS 1.76” Type 12Meg monochrome progressive Electronic Imager (CMOSIS: CMV12000) CMOS (CMOSIS: CMV12000) specifications Global Shutter...

  • Page 7: Spectral Sensitivity Characteristics

    No.14S056-11 2.2 Spectral Sensitivity Characteristics 2.2.1 STC-CMC120APCL/ STC-CMB120APCL Figure 2. Spectral Sensitivity Characteristics STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...

  • Page 8: Connector Specifications

    No.14S056-11 2.3 Connector specifications CH1: 26-pin SDR connector 26-pin SDR connector (Medium / Full Camera (BaseCamera Link Connector) Link Connector) Power/IO connector Figure 3. Back View 2.3.1 Camera Link connectors: SDR(3M) equivalent x 2 (CAUTION) This product is PoCL type. When the frame grabber board and the cable are applicable for the PoCL, the frame grabber board supplies the power to the camera.

  • Page 9: Power/Io Connector

    No.14S056-11 2.4 Power/IO connector: HR10A-7R-6PB (Hirose) or equivalent. This connector is for 12Vdc power input and the input and output signals. The trigger input and sync input /output signals can be assigned through the camera setting communication. Pin assignment Table 3. Pin assignment Pin No Signal Name IN/OUT...
  • Page 10 No.14S056-11 Input Signal Circuit Camera +3.3V +3.3V 6Pin Conector 10kΩ Pin. 2 or 3 or 4 or 5 Camera 2,3,4, input User INPUT (to FPGA) 100Ω SN74AVC4T774 Figure 4. Input Signal Circuit Input Signal Circuit Example +3.3V +3.3V 6Pin Conector 47kΩ...

  • Page 11: No.14S056

    No.14S056-11 Output Signal Circuit/ Example Camera +3.3V +3.3V 6 Pin Conector 10kΩ Pin. 2 or 3 or 4 or 5 Camera User Output 2,3,4, output Voltage 0 to (from FPGA) +3.3V DC 100Ω SN74AVC4T774 Figure 6. Output Signal Circuit Example LED information Table 4.

  • Page 12: Dimensions

    No.14S056-11 2.5 Dimensions M42 Mount Model Figure 8. M42 Mount Model STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
  • Page 13 No.14S056-11 F Mount Model Figure 9. F Mount Model STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...

  • Page 14: Camera Installation

    No.14S056-11 Camera Installation For the installation of this camera, these equipment as bellow are required. Control software or Serial communication software to access the camera register.  As for using the software, please refer to another chapter. Software. As for accessing the register, please refer to the ONTROL HE COMMUNICATION PROTOCOL SPECIFICATIONS...

  • Page 15: The Camera Output Timing Charts

    No.14S056-11 The camera output timing charts 4.1 The horizontal timings (CMC120APCL) As for the vertical timing, please refer to The Vertical timings. Highs Speed Clock and Low Speed Clock are existed as Pixel Clock. 4.1.1 10 Taps (1X10-1Y) / Horizontal：4,090 pixels 1 CLK = 11.764 nseconds (85MHz) 28 - 29 CLK One horizontal (1H)
  • Page 16 No.14S056-11 The pixel order for the Image 4084 4085 4086 4087 4088 4089 4090 ..4,090 pixels TAP1: DA output pixels 4021 4031 4041 4051 4061 4071 4081 ..TAP2: DB output pixels 4022 4032 4042 4052 4062 4072 4082 ..

  • Page 17: Taps (1X8-1Y) / Horizontal 4,096 Pixels

    No.14S056-11 4.1.2 8 Taps (1X8-1Y) / Horizontal 4,096 pixels 1 CLK = 11.764 nseconds(85MHz) 1 CLK = 23.524 nseconds(42.5MHz) H Total(696 - 697clk) One horizontal (1H) LVAL 512 CLK 14 - 15 CLK Video out (Tap1:DA) Video out (Tap2:DB) Video out (Tap3:DC) Video out (Tap4:DD)
  • Page 18 No.14S056-11 The pixel order for the Image 4090 4091 4092 4093 4094 4095 4096 ..TAP1: DA output pixels 4,096 pixels 4041 4049 4057 4065 4073 4081 4089 ..TAP2: DB output pixels 4042 4050 4058 4066 4074 4082 4090 ..

  • Page 19: Taps (1X4-1Y) / Horizontal：4,096 Pixels

    No.14S056-11 4.1.3 4 Taps (1X4-1Y) / Horizontal：4,096 pixels 1 CLK = 11.764 nseconds(85MHz) 1 CLK = 23.524 nseconds(42.5MHz) 1032 CLK One horizontal (1H) LVAL 1024 CLK 28 - 29 CLK Video out (Tap1: DA) Video out (Tap2: DB) Video out (Tap3: DC) Video out (Tap4: DD)

  • Page 20: Taps (1X3-1Y) / Horizontal 4,092 Pixels

    No.14S056-11 4.1.4 3 Taps (1X3-1Y) / Horizontal 4,092 pixels 1 CLK = 11.764 nseconds(85MHz) 1 CLK = 23.524 nseconds(42.5MHz) 1403 or 1404 CLK One horizontal (1H) LVAL 39 or 40 CLK 1364 CLK Video out (Tap1:DA) Video out (Tap2:DB) Video out (Tap3:DC) Video output Horizontal...

  • Page 21: The Vertical Timings

    No.14S056-11 4.2 The Vertical timings As for Horizontal timing, please refer to the The horizontal timings (CMC120APCL). Three Video scan modes exist. The detail for these three scan modes are described as below. Full scan: All of line and pixel output from the camera Binning: Averaged pixel value output from the camera Subsampling: Skipped the lines and pixels output from the camera Overview of Full scan...

  • Page 22: Aoi Output Timing

    No.14S056-11 AOI Output Timing This camera can be set the AOI up to 8.  Variable Partial Start Line(VAS*), Variable Partial Effective Line(VAH*), Horizontal Start  Position(HAS*), Horizontal Effective Pixel(HAW*) can be set for each eight regions. One region can be set on horizontal direction.
  • Page 23 No.14S056-11 Camera Link Output timing on AOI is as follow. AOI_A LVAL AOI_B LVAL AOI_C LVAL AOI_D LVAL AOI images output as consecutive image. Horizontal pixel number can be reduced through Horizontal Effective Pixel(HAW*) on AOI. AOI on Color camera Variable Partial Start Line(VAS*), Variable Partial Effective Line(VAH*) can be set two lines each.
  • Page 24 No.14S056-11 Formula of maximum frame rate ・10TAP CameraLink Clock: 85MHz 50 / 258 / Variable Partial Effective Line(VAH*) +38) x 10^6 [fps] (Round down numbers beyond the second decimal point) ・10TAP CameraLink Clock: 42.5MHz 25 / 258 / Variable Partial Effective Line(VAH*)+38) x 10^6 [fps] (Round down numbers beyond the second decimal point) ・8TAP CameraLink Clock: 85MHz 41.6 / 258 / Variable Partial Effective Line(VAH*)+38) x 10^6 [fps] (Round down numbers beyond the second decimal point) ・8TAP CameraLink Clock: 42.5MHz, 4TAP CameraLink Clock: 85MHz...

  • Page 25: Camera Link Bit Assignment

    No.14S056-11 Camera Link bit assignment 10TAP8bit XCLK DC1 DC0 FVAL LVAL DC5 DC4 DC3 DA1 DA0 DA4 DA3 DA2 DA1 DA0 YCLK LVAL DF3 DF2 LVAL DF1 DF0 ZCLK LVAL LVAL DA0 to DA7: 8bit data for one pixel from TAP1 DB0 to DB7: 8bit data for one pixel from TAP2 DC0 to DC7: 8bit data for one pixel from TAP3 DD0 to DD7: 8bit data for one pixel from TAP4...
  • Page 26 No.14S056-11 8TAP8bit XCLK DVAL FVAL LVAL DC5 DC4 DC3 DC2 DC1 DC0 DA1 DA0 DA5 DA4 DA3 DA2 DA1 DA0 YCLK DVAL FVAL LVAL DF5 DF4 DF3 DF2 DF1 DF0 ZCLK DVAL FVAL LVAL DA0 to DA7: 8bit data for one pixel from TAP1 DB0 to DB7: 8bit data for one pixel from TAP2 DC0 to DC7: 8bit data for one pixel from TAP3 DD0 to DD7: 8bit data for one pixel from TAP4...
  • Page 27 No.14S056-11 4TAP8bit 4TAP10bit XCLK XCLK DVAL FVAL LVAL DC5 DC4 DC3 DC2 DVAL FVAL LVAL DC1 DC0 DA1 DA0 DA5 DA4 DA3 DA2 DA1 DA0 DA1 DA0 DA8 DA5 DA4 DA3 DA2 DA1 DA0 YCLK YCLK DVAL FVAL LVAL DVAL FVAL LVAL DC8 DC5 DC4 DC3 DC2 DC1...
  • Page 28 No.14S056-11 3TAP8bit 2TAP8bit XCLK XCLK DVAL FVAL LVAL DC5 DC4 DC3 DC2 DVAL FVAL LVAL DC1 DC0 DA1 DA0 DA5 DA4 DA3 DA2 DA1 DA0 DA1 DA0 DA5 DA4 DA3 DA2 DA1 DA0 DA0 to DA7: 8bit data for one pixel from TAP1 DA0 to DA7: 8bit data for one pixel from TAP1 DB0 to DB7:...

  • Page 29: Camera Link Tap Geometry

    No.14S056-11 Camera Link TAP Geometry 4.6.1 10TAP (1X10-1Y) Sep X =10 Tap1 Tap2 Tap3 Tap4 Tap5 Tap6 Tap7 Tap8 Tap9 Tap10 4.6.2 8TAP (1X8-1Y) Sep X = 8 Tap1 Tap2 Tap3 Tap4 Tap5 Tap6 Tap7 Tap8 STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc.

  • Page 30: 4Tap (1X4-1Y)

    No.14S056-11 4.6.3 4TAP (1X4-1Y) Sep X = 4 Tap1 Tap2 Tap3 Tap4 4.6.4 2TAP (1X2-1Y) Sep X = 2 Tap2 Tap1 STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...

  • Page 31: Bayer Pattern For Color Model (Only Stc-Cmc120Apcl)

    No.14S056-11 4.7 Bayer pattern for color model (Only STC-CMC120APCL) STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...

  • Page 32: Camera Function Modes

    No.14S056-11 Camera function modes Normal mode 5.1.1 Normal mode (Electronic shutter) I n t e r n a l V D E x p o s u r e t i m e C C D e x p o s u r e V i d e o o u t STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide...

  • Page 33: Pulse Width Trigger Mode

    No.14S056-11 Pulse width trigger mode In this trigger mode with positive polarity, the camera exposure starts at the rising edge of the trigger pulse and stops at the falling edge of the trigger pulse. Therefore, In the case of the exposure positive polarity is selected, the exposure periods are the high states of the trigger pulse.

  • Page 34: Edge Preset Trigger Mode

    No.14S056-11 Edge Preset Trigger mode In this trigger mode, the camera exposure starts at the rising edge of the trigger pulse or negative edge when setting is “Trigger Polarity::Negative”, the camera exposure starts at the falling edge of the trigger pulse. Exposure duration time is preset by the “Electrical Shutter”...

  • Page 35: The Communication Protocol Specifications

    No.14S056-11 The communication protocol specifications This camera has the communication function that enables external devises like PC control the camera functions. Please use “CLCtrl2 (Version1.01 or later)” communication software or use following the communication protocol to communicate to the camera. Note.

  • Page 36: The Communication Format

    No.14S056-11 6.3 The communication format A. The sending data format from the PC to the camera is as follows: a. Send the read command Device code Read Page selection Command code Data length Data (8bit) (6bit) (1bit) (1bit) (8bit) (8bit) (1byte) (8bit) b.

  • Page 37: The Camera Control Commands

    No.14S056-11 6.4 The camera control commands 6.4.1 The camera commands list(Device Code:00H) Note. 1: The data unit of the each command is 1byte (8bit). Note. 2: The data can be saved to the EEPROM if “x” in the “Save to EEPROM” column in the list. The camera is operating with the data of the EEPROM when the power on the camera.
  • Page 38 No.14S056-11 Command Read Save to Function Initial Data /Write EEPROM Data Range The start line of the variable partial scanning A (16bit: D[7..0]) 0 to 3,068 The start line of the variable partial scanning A (16bit: D[15..8]) The start line of the variable partial scanning B (16bit: D[7..0]) 0 to 3,068 The start line of the variable partial scanning B (16bit: D[15..8]) The start line of the variable partial scanning C (16bit: D[7..0])
  • Page 39 No.14S056-11 Command Read Save to Function Initial Data /Write EEPROM Data Range The start Pixel of the variable partial scanning A (16bit: D[7..0]) 0 to 4095 The start Pixel of the variable partial scanning A (16bit: D[15..8]) The start Pixel of the variable partial scanning B (16bit: D[7..0]) 0 to 4095 The start Pixel of the variable partial scanning B (16bit: D[15..8]) The start Pixel of the variable partial scanning C (16bit: D[7..0])

  • Page 40: Description Of The Camera Control Commands (The Under Line Settings Are The Factory Default Settings)

    No.14S056-11 6.4.2 Description of the camera control commands (The under line settings are the factory default settings) Command No. Command Descriptions 10H: [The camera function mode 1] Initial data: MOD1[7..0] = 01H MOD1[7..0] Sets the camera function mode. D[7..0] No function Set always as "0"...
  • Page 41 No.14S056-11 Command No. Command Descriptions 20H: [The exposure time of the electronic shutter] Initial data: SVR[23..0] = 1,536, Range: 1 to 16,777,215 SVR[7..0] Sets the preset shutter speed for electronic shutter. 21H: D[7..0] SVR[15..8] 22H: SVR[23..16] Case 10h.0 =0 (Exposure time on Usec unit) ・10TAP Exposure time (shutter speed) = ((SVR[23..0] -1) x 258 + 1020 ) x 10 / 250 Unit: usec...
  • Page 42 No.14S056-11 Command No. Command Descriptions 47H: [HDR] Initial data: HDR[7..0] = 1 HDR[7..0] Set the Slope number on HDR. D[7..0] HDR Mode D7 to D6: 0:Disable, 3:Enable No function D5 to D2: Sets always as "0000" Number of Slopes D1 to D0: 0：No function 1：No function Slopes...
  • Page 43 No.14S056-11 Command No. Command Descriptions 78H: [Test Pattern] Initial data: TESTP [7..0] = 00H TESTP[7..0] Sets the test pattern video output. D[7..0] D7 to D5: 0: Normal Video Image 1: Gray Scale 2: Ramp 3: 100% White 4: White Clip 6: Color Bar(RGB BAYER) Others: Black 79H:...
  • Page 44 No.14S056-11 Command No. Command Descriptions 90H: [Vertical AOI Start Line AOI_A] Initial data: ：VASA[15..0] = 0、Range: 0 to 3,068 VASA[7..0] Sets Vertical AOI Start Line AOI_A. 91H: The value should be set 4 Lines each. VASA[15..8] (e.g.：0、4、8、to 3,068） 92H: [Vertical AOI Start Line AOI_B] Initial data: ：VASB[15..0] = 0、Range: 0 to 3,068 VASB[7..0] Sets Vertical AOI Start Line AOI_B.
  • Page 45 No.14S056-11 Command No. Command Descriptions A0H: [Vertical AOI Effective Line AOI_A] Initial data: VAHA[15..0] = 3,072、Range: 4 to 3,072 VAHA[7..0] Sets the number of the effective lines (image height) of the variable partial scanning. A1H: The value should be set 4 Lines each. VAHA[15..8] The camera works with full scanning, when the total effective lines of the eight partial.
  • Page 46 No.14S056-11 Command No. Command Descriptions B0H: [Horizontal AOI Start Pixel AOI_A] Initial data: HASA[15..0] = 0、Range: 0 to 4,095 HASA[7..0] Sets Horizontal AOI Start Pixel AOI_A. B1H: HASA[15..8] B2H: [Horizontal AOI Start Pixel AOI_B] Initial data: HASB[15..0] = 0、Range: 0 to 4,095 HASB[7..0] Sets Horizontal AOI Start Pixel AOI_B.
  • Page 47 No.14S056-11 Command No. Command Descriptions C0H: [Horizontal AOI Effective Pixel AOI_A] Initial data: HAWA[15..0] = 4,096、Range: 0 to 4,096 HAWA[7..0] Sets the number of effective pixels (image width). The effective pixels is same as DVAL. C1H: Variable value depends on Tap number of CameraLink. HAWA[15..8] When effective pixels (image width) is 0 or larger than horizontal pixels, Effective pixels (image width) = Horizontal pixels...
  • Page 48 No.14S056-11 Command No. Command Descriptions DEH: ] Initial data: DEF_M [7..0] = 1 Pixel defect correction mode1 DEF_M[7..0] Sets the pixel defect correction. As for the x-y coordinate of defect pixel, please refer to the Device Code:3AH D[7..0] D7 to D4: Upper Address 0 to 9 D3 to D2:...

  • Page 49: Camera Control Command List (Device Code:3Ah)

    No.14S056-11 6.4.3 Camera Control Command list (Device Code:3AH) The actual 256points of Pixel Blemish Correction (PB Correction) Values are stored on this address. # 600points # The data size of each Command No. is 1 Byte(8bit) # “EEPROM” on the table shows the access on EEPROM (○: can be saved on EEPROM, ×: can not be saved on EEPROM) At the shipping time, defect pixel were corrected and stored the information into EEPROM for each camera.
  • Page 50 No.14S056-11 Device Code：3AH (Device Code 00H DEh[7..4] = 2) Command No. EEPROM Function Initial Data Data Range X129 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 4095 ○ X129 point of PB Correction (16bit：D[15..8]) (PB Correction OFF) ○ Y129 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 3071 ○...
  • Page 51 No.14S056-11 Device Code：3AH (Code 00H DEh[7..4] = 5) Command No. EEPROM Function Initial Data Data Range X321 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 4095 ○ X321 point of PB Correction (16bit：D[15..8]) (PB Correction OFF) ○ X321 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 3071 ○...
  • Page 52 No.14S056-11 Device Code：3AH (Device Code 00H DEh[7..4] = 8) Command No. EEPROM Function Initial Data Data Range X513 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 4095 ○ X513 point of PB Correction (16bit：D[15..8]) (PB Correction OFF) ○ X513 point of PB Correction (16bit：D[7..0]) FFFFh 0 to 3071 ○...
  • Page 53 No.14S056-11 Sequence for the command saves to the EEPROM Please use below sequence for the command saves to the EEPROM 1) Set “1” to the 80H.0 for the accept “write control to the EEPROM”. 2) Send the command and the save data with the EEPROM access command, which is set “1” for the page selection.

  • Page 54: Control Software

    No.14S056-11 Control Software 8.1 Summary After installing the control software and launch the CLCtrl2.exe, main window appears as below. Menu As for the detail, please refer to the next page. Camera Setting Parameters As for the detail, please refer to the next chapter OFTWARE UNCTION TANDARD...

  • Page 55: File

    No.14S056-11 8.1.1 File Open[From File to Register] Open the camera setting file (.i2c). Save as[From Register to File] Save the current camera setting data on the register to the PC as i2c file. Open[From File to EEPROM] Open the camera setting file (.i2c) that is read at power on. Save as[From EEPROM to File] Save the camera setting data on EEPROM to the PC as i2c file.

  • Page 56: Help

    No.14S056-11 8.1.4 Help Advanced Operation When password(sentechcamera) is input, additional functions appear for power user. SP Pin tab can be used. Version Information Software information window appear. 8.2 Software Function(Standard) This tab has basic camera function. the number(like [10H.5]) beside of the function is register address. When direct register access is needed.

  • Page 57: Mode

    No.14S056-11 8.2.2 Mode Trigger Polarity Positive Positive signal is availabe as Trigger Negative Negative signal is availabe as Trigger Binning Mode Normal Disable the binning Binning Enable the binning. As for the actural procedure,please refer to the Binning[2AH.5-4],Sub[2AH.1-0]. Averaged pixel data make decreasing the noise level.

  • Page 58: Gain

    No.14S056-11 8.2.3 Gain Digital Gain The value of digital gain.As for the detail of gain calucuration, please refer to the 31H. Trigger Trigger Delay The delay time for the trigger.. As for the detail of delay time calculation, please refer to the 28H.

  • Page 59: Software Function (Partial)

    No.14S056-11 8.3 Software Function (Partial) Variable partial Partial scan can be set. As for the detail please refer to HE COMMUNICATION PROTOCOL SPECIFICATIONS 8.4 Software Function Advanced) This tab is used for factory setting. Please do not use this tab. 8.5 Software Function (HDR) This tab uses for the power user to control the Gamma deeply.

  • Page 60: Actual Camera Setting & Technical Notes

    No.14S056-11 Actual Camera Setting & Technical Notes Using the Trigger Signal through 6pin 1.Select the “[0]Trigger Shutter Mode(Long Exposure)” on Contiue/Trigger Shutter Mode Selection at Standard tab through the control software(CLCtrl2). 2. Select the ”[0H] FIL_TRG/LVAL/FVAL_TRG_IN” on SP Pin Signal Selection at SP_Pin tab. 3.

  • Page 61: Revision History

    No.14S056-11 10 Revision History Revisions Date Changes Note 2014/01/20 Released as Production model 2014/07/01 Revised Company name Support 10,8,4,3,2TAP model Revised Aluminum (AC) to Aluminum alloy Revised ROI information 2014/09/03 Revised Formula on Shutter Speed(20H) 2014/10/06 Revised Information on 11H,4CH,4DH,56H,57H,5BH,5CH,A2-AFH,EEH,DEH 2014/11/28 Revised Minimum scene illumination and Shutter speed 2014/12/12...
  • Page 62 No.14S056-11 9F Ebina Prime Tower 9-50 Chuo 2 Chome Ebina-city, Kanagawa 243-0432, JAPAN TEL +81-46-236-6660 FAX +81-46-236-6661 URL http://www.sentech.co.jp STC-CMC120APCL, STC-CMB120APCL Specifications and Users guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
