oventrop DynaTemp RBG-C F Installation Instructions

EN
Before installing the wireless room control unit "RBG-C F"
(item no. 1153050) as well as its accessory components,
please read and follow the installation instructions and
operating manual in full!
Installation, commissioning, operation and maintenance
must only be performed by trained and specialised staff in
compliance with applicable rules and regulations!
The installation instructions, the operating manual for the
respective "DynaTemp" system as well as all additionally
applicable documentation must be forwarded to the system
operator!
Content
1 General information ........................................................... 1
2 Safety instructions ............................................................. 2
3 Transport, storage and packaging ..................................... 2
4 Technical specifications ..................................................... 2
5 Dimensions ....................................................................... 2
6 Configuration and function ................................................. 3
7 Assembly and installation .................................................. 3
8 Commissioning .................................................................. 3
9 Information about radio ...................................................... 4
10 Teaching in and deleting.................................................... 5
11 Accessories ....................................................................... 5
12 Maintenance and servicing ................................................ 5
13 Declaration of conformity ................................................... 5
14 Warranty ............................................................................ 5
Fig. 1.1 Wireless room control unit "RBG-C F", solar-powered
OVENTROP GmbH & Co. KG
Paul-Oventrop-Straße 1
59939 Olsberg
Deutschland
Phone +49 (0) 29 62 82-0
Fax +49 (0) 29 62 82-400
E-mail mail@oventrop.de
Internet www.oventrop.com
For an overview of our global presence
visit www.oventrop.com.
Valves, controls and systems
Installation instructions for first commissioning by the specialised installer
1

General information

1.1 Information about the installation and operating in-
structions
These installation instructions are to be used by the trained and
specialised staff to properly install, commission and configure
the wireless room control unit "RBG-C F" for the first time. Fol-
lowing installation, additional documentation like for example the
operating manual for the associated system "DynaTemp" is to
be downloaded from the control and regulation unit (DDC) in the
"HELP/INFO - Documentation" menu item with an Internet
browser, e.g. "Mozilla Firefox".
Additionally applicable documentation - instructions for all sys-
tem components as well as applicable technical rules - are to be
complied with.
1.2 Safekeeping of documentation
These installation instructions are to be stored in a safe place by
the system operator for later use.
1.3 Symbol explanation
Safety guidelines are displayed by symbols. These guidelines
are to be observed to prevent accidents, damage to property
and malfunctions.
DANGER indicates a hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation
which, if not avoided, may result in minor or moderate injury.
NOTICE indicates a situation which, if not
addressed, may result in property damage.
1.4 Copyright
These installation instructions are protected by copyright.
Usage of the control and regulation unit with its accessory com-
ponents is subject to a license.
The license text can be found on the control and regulation unit
in the "HELP/INFO - Documentation" menu item. By using the
product you agree to the license agreement.
Subject to technical modification without notice.
"DynaTemp";
"RBG-C F"
115305081 09/2019
