1. Turn Key Off.
TROUbLESHOOTING

CONFIGURATION MODE

Configuration mode is an onboard diagnostic utility that
configures controller software to operate optional equip-
ment and to electronically adjust certain output func-
tions .
1 . key switch off . press and hold the configuration
mode button .
STP001
1. Turn Key Off.
Tennant Quantum
UI ver X.X
2 . key switch on . release the configuration mode
button when "ConfIG mode" appears on the LCd .
STP002
CONFIG MODE
Operational Matrix:
4-4 Scrub Head
Down
3 . press and release the brush pressure button to enter
4 . press and release the configuration mode button to
Enabled Disabled
• 1-STEP Scrub ON
• Squeegee/Vac ON
Configuration mode . "C1:disk/Cyl" will appear on the
LCd .
T12 XP
T12 STANDARD
scroll through a list of utilities as shown below .
C5:Main Press #1
XX Amps
• 1-STEP Scrub OFF
T12 Service Information 9009917 (12-12)
• Squeegee/Vac OFF
• Recovery Tank Full
• Low Batt Voltage
C1:Disk/Cyl
C1:Disk/Cyl
C2:Ec/No
C4:Reset Press.?
C5:Main Press #1
11.0 A
C6:Main Press #2
16.0 A
C7:Main Press #3
22.0 A
C8:Transport Spd
XX.X MPH
C9:Scrubbing Spd
XX.X MPH
C10:Propel H.M.
XXXX.X Hrs
C11:Main Water
Low/Med/High
C12:Side Brush?
Sweep/Scrub
C13:Scrub H.M.
XXXX.X Hr
C14:Reset
C15:Battery Type
C16:Dwn Pres Tst
Operational Matrix:
Enabled
• 1-STEP Scrub ON
• Fwd/Rev Propel
Scrub Head
Down
