Navitron SFB Series Installation Manual page 9

SFB155818
No.
1 (All-glass Evacuated Tubular Solar Collector
with Heat Pipe,Ф58mm*1800mm)
2
3 Thermal silicon grease（80g）
4
5
6 Aluminum horizontal bar
7 Black nylon screw cup
8
9 White Nylon clips for reflectors
screw ,washer
10
and nut
Items
SFVB
Manifold Box
Decoration cover
Vertical Bar
Reflectors
M8×10（screw, nut, washer）
M6×10
(screw+ washer)
already affixed to manifold
M6×20 for horizontal bar
(screw+ nut + blackcap)
Table 3.6
Qty. of spare
Qty.(pcs)
part
15 -
1 -
1 -
15 1
2 -
1 -
15 1
14 -
28 -
4 1
4 1
2 -
Total
15
1
1
16
2
1
16
14
28
5
5
2
9
