Navitron SFB Series Installation Manual page 7

SFB304715
No.
1 (All-glass Evacuated Tubular Solar Collector
with Heat Pipe,Ф47mm*1500mm)
2
3
Thermal silicon grease（80g）
4
5
6 Aluminum horizontal bar
7 Black nylon screw cup
8
9 White Nylon clips for reflectors
screw ,washer
10
and nut
Items
SFVB
Manifold Box
Decoration cover
Vertical Bar
Reflectors
M8×10（screw, nut, washer）
M6×10
(screw+ washer)
already affixed to manifold
M6×20 for horizontal bar
(screw+ nut + blackcap)
Table 3.4
Qty. of spare
Qty.(pcs)
part
30 -
1 -
1 -
30 1
3 -
1 -
30 1
29 -
58 -
6 1
6 1
2 -
Total
30
1
1
31
3
1
31
29
58
7
7
2
7
