jablotron OS-311 FORTE Installation

Outdoor Siren OS-311 FORTE
The OS-311 FORTE is a high powered outdoor electronic siren in a plastic case.

Specifications

voltage
current consumption
siren loudness
cover
Environmental Class IV - Outdoor - General (-25 o to +60 o C)
according to EN 50131-1
Complies with the essential requirements of: 89/336/EC EMC
Directive - Protection concerning electromagnetic compatibility
when is used for its intended purpose. Original of the conformity
assessment can be found at the web page www.jablotron.cz,
section Technical support.
Installation
Remove plastic cover by removing two screws (under plastic caps) with a
screwdriver.
Route all cabling into the siren
through a hole in the rear part.
Hang the siren housing on the top
screw and fix it using two other
screws.
Do not forget to switch the control
panel to the service mode before you
connect the cabling to the siren ! For
maximum siren output use cables
with sufficient cross section of wires.
Operation
As long as the voltage is applied to the +12V input the siren sounds and flash light
is active.
Note: Although this product does not contain any harmful materials we
suggest you to return the product to the dealer or directly to the
producer after usage
Outdoor Siren OS-311
10 -15V DC
1A
piezo siren 118 dB
IP44
1/2
Pod Skalkou 33
466 01 Jablonec nad Nisou
Czech Republic
Tel.: +420 483 559 999
fax: +420 483 559 993
Internet: www.jablotron.cz
MDS51702
