Gunlocke SILEAEH Installation Instructions Manual page 25

PEDESTAL TYPES
DRAWER PEDESTALS
(DRAWERS REMOVED)
REMOVE & LABEL DRAWERS
RE-INSTALL IN SAME LOCATIONS
UNASSEMBLED UNITS
WORKSURFACE JUNCTION SUPPORT
ALIGNMENT
DOWELS
BACK PANEL ATTACHMENT
REMOVABLE BACKS
SPRING CLIPS
ALIGNMENT
DOWELS
CHASSIS ASSEMBLY
SHELF PEDESTALS
(SHELF/ INSET BACK REMOVED)
REAR GLIDE ACCESS
REMOVE SHELF (QUICK RELEASE)
INSET BACK IS ATTACHED WITH SPRING CLIPS
AT THE TOP - PULL FORWARD TO REMOVE
CAM FASTENERS
CAM FASTENERS
ALIGNMENT DOWELS
REAR GLIDE ACCESS
RH "L" SUPPORT
STRUCTURAL BACKS/ FILLER STRIP
FALSE PEDESTALS
IN-LINE "T" SUPPORT
3/4"
SCREWS
PAGE 2 OF 7
