Gunlocke SILEAEH Installation Instructions Manual page 10

SHOE RACK
SHOE RACK
SCREW
5/8"LG
BLACK
PAN HEAD
(8 PLCS)
LAMINATE DR HINGE
HINGE HOOKS
TO ACCEPT
LATCH PINS
LAMINATE
HINGE
PRESS IN
PLACE AND
TIGHTEN
SCREWS
FOOT STOP
SCREW FOOT STOP
IN PLACE
TWO SETS OF HOLES
PROVIDED FOR
ADJUSTMENT
CATCH
COAT HOOK
COAT
HOOK
SCREW
M4 x .7
25mm LG
PAN HD
HINGE DR GLASS
SCREW
DIRECTLY
INTO ALUM
FRAME,
PILOT HOLES
PROVIDED
BASE PLATE LATCH PINS
AND PIVOT INTO CATCH
BASE PLATE
LATCH PINS
HINGE CONNECTION
HOOK HINGE OVER
PAGE 2 OF 2
