16. LED STATUS INDICATOR TABLE
LED STATUS
Power LED
Red ON
Red Flashing
LED STATUS
Charge LED
Orange Flashing Fast
Orange Flashing Fast
Orange Flashing Fast
Orange ON
LED STATUS
Charged / Error LED
Green ON
Green Flashing
Red ON
Red ON
Red ON

17. CHARGING CURVE

Voltage
(VOLTS)
Current
(AMPS)
QUALIFICATION
Checks battery
condition to
determine whether
the rejuvenation
stage or charge
cycle is required.
Indicates AS power is ON and no Battery has been detected. ECO Mode.
Soft start charging timed out if Orange Charging LED is also flashing fast
Bulk charging timed out if Orange Charging LED is also flashing slow
Note: When the unit is in ultra low power consumption mode (ECO Mode), this will be indicated
by the Power LED flashing RED. The unit will automatically go into this mode if no battery is
detected or connected.
PROCESSUS DE CHARGE/DE MAINTIEN
REJUVENATION SOFT START
Automatic stage Increases your
for batteries in poor battery life by gently
condition. Breaks starting to charge
down sulphation the battery until
using new patented the battery reaches
techologie. a set voltage.
DESCRIPTION
Indicates AC power is ON
DESCRIPTION
Qualification and battery condition check
Battery rejuvenation
Soft start charging
Bulk charging or absorption charging
DESCRIPTION
Battery is fully charged and is in Float/Maintenance mode
Battery analysis has failled
Short circuit or reverse polarity
BULK CHARGE ABSORPTION
Reduces charging Uses constant
time by delivering voltage and
maximum charge ensures the battery
until the battery receives a full
reaches a set charge without
voltage. overcharginf the
battery.
MODEL: EWC612-1
USER'S MANUAL
ANALYSIS MAINTENANCE
Check the Special pulse
battery condition charge for
to ensure it's long-term
fully charge. maintenance to
ensure the battery
FLOAT
is in optimal
Maintains the
condition.
battery at 100%
charge.
