ECLIPSE P300 / P300A
panel removal
There are three panels that can be removed from the P300(A) Chassis; the left side
tempered glass panel, the right side panel and the front panel. Follow these steps below.
STEP 1.
LEFT SID E PANEL
a. b.
L O O S E N T H U M B S C R E W S A N D T I L T P A N E L F O R W A R D .
S L I D E T O T H E L E F T .
LOO SE N:
2x
P ANE L RE -INSTALLATI ON
F O L L O W S T E P S I N R E V E R S E O R D E R .
STEP 2.
RIGHT SIDE P ANE L
L O O S E N T H U M B S C R E W S A N D S L I D E
T H E S I D E P A N E L O F F .
LOO SE N:
2x
With the P300 model you can access the
dust lters after removing the front panel.
We recommend to clean the dust lters every
month for optimal performance.
INSTALLATION GUIDE V1.0
c.
P U L L U P W A R D T O R E M O V E .
STEP 3.
FR ON T P AN EL
R E M O V E F R O N T P A N E L B Y P U L L I N G
O N I T F R O M B E L O W
ECLIPSE P300 / P300A
HARDWARE INSTALLATION
STEP 4.
M OTHERBOA RD
I N S T A L L T H E A T X M O T H E R B O A R D W I T H 9 M O T H E R B O A R D S C R E W S
I N STAL L :
9x
STEP 5.
P OWER SUP PL Y
I N S E R T T H E P O W E R S U P P L Y I N T O T H E C H A S S I S
A N D T H E N S E C U R E T H E P O W E R S U P P L Y W I T H 4 P S U S C R E W S
IN STAL L :
4x
STEP 6.
2 .5 " SSD
I N S T A L L T H E S S D D R I V E W I T H 4 S S D S C R E W S A N D
M O U N T I N T O T H E C H A S S I S .
A SECOND OPTIONAL SSD BRACKET CAN BE INSTALLED.
2.5" SSD DRIVES CAN ALSO BE INSTALLED INTO THE 3.5" DRIVE BAYS.
IN STAL L :
4x
STEP 7.
3 .5 " HD D
R E M O V E T H E H D D T R A Y B Y P U L L I N G O U T W A R D . I N S T A L L T H E H D D
D R I V E I N T H E T O O L L E S H D D T R A Y A N D S L I D E T H E M O U N T E D
H D D T R A Y B A C K I N T O T H E C H A S S I S .
INSTALLATION GUIDE V1.0
M i c r o - A T X
If installing a Micro-ATX
motherboard, install the extra
stando supplied and consult your
motherboard manual for further
instructions.
The HDD Tray can also
hold a 2.5" SSD
