B-K lighting SIGN STAR Series Installation Instructions Manual page 6

with
Sign Lighting Installation Instructions
This product is available with Adjust-e-Lume™ (Patent Pend.) for Dynamic Lumen Output Control
Warning! The light output of this product may be dynamically adjusted as desired to raise and lower light levels. Please ensure the fi xture is set
to the appropriate light level desired during installation.
To Change Lumen Output (when required).
1. Use 5/64" Allen wrench to loosen #8-32
stainless set screw and remove cap.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING
IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
SIGN STAR™ AND TWIN SIGN STAR™
TECHNOLOGY
2. With flat head screw driver rotate dial to
desired lumen output.
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
PROJECT:
TYPE:
3. Place cap on fixture and tighten set screw.
3167387
RELEASED
12-12-11
ETL LISTED
CONFORMS TO ANSI/UL STANDARD 1838,
CERTIFIED TO CSA STD C22.2 NO.250.7
CSA STD C22.2 TIL B-58A
REFERENCE NUMBER
INS000940
