Section 3: System Operation

Daily Startup

1. Check the water reservoir level before beginning Startup for the first time.
The toggle switch labeled, AC Power, should have been left on after the last use. If
2.
not, do the following:
• On the front panel of the Surelite power unit, flip the toggle switch up that is
labeled AC P
LEDs on the front panel display will readout 888, software rev. #, then O
The "Power On" button is located on the rear panel of the laser head.
• After approximately 6 seconds, the L
located on the top of the laser head and on the front panel of the power supply.
3. Insert the key into the keyswitch and rotate it counter-clockwise to the On postion.
The readout LED will monmentarily display the following.
Total # flashlamp discharges
Water flow startup
Flashlamp discharge
frequency
4. Press the SELECT button and toggle the LED display through these six modes to
verify the accuracy of all the settings. The normal values are:
Rep Rate
Q-switch
Pulse Division
Pump Voltage
Serial Mode
External Mode
5. Press the START/STOP button and its LED will come on. The laser head will now
flash at the designated frequency. Allow the system to run for 15-20 minutes to
thermally stabilize the YAG head before proceeding.
6. Put on laser safety goggles.
7. On the front of the laser bench, slide the exit port shutter to the OPEN position.
8. Press the SHUTTER button and its LED will come on. An audible click will be
heard from laser bench as the intra-cavity shutter withdraws from the oscillator. The
system should now lase.
(this is the On position). After a quick diagnostic check, the
OWER
Displays as a series of 3 displays for millions,
thousands, and hundreds.
FLo displays while system waits for water flow
to be verified in the laser heads.
Displays the last saved rep, in Hertz
(flashes/second).
Factory set for either 10 or 20 Hz
Set to the value listed in the Quality Assurance
Document at the front of the manual
P01 (laser output with every discharge of
flashlamp)
Set to the value listed in the Quality Assurance
Document at front of manual.
SoF (serial port off)
EoF (External mode off)
LASER RADIATION!
The next step results in laser output.
O lights will turn on. They are
ASER N
.
FF
