Table 6 ASCI response
Returns Description
00 Normal return
01 Surelite not in serial mode
02 Coolant flow interrupted
03 Coolant temperature over temp
04 (not used)
05 Laser head problem
06 External interlock
07 End of charge not detected before lamp
fire
08 Simmer not detected
09 Flow switch stuck on.
The response to SC (Shot count) is a 9 digit ASCII code terminated by a Carriage Return. An
example is shown in Table 7 below.
Table 7 SC response
Returns Description
000123456 shot count = 123,456

To disable RS232

1. With system running, transmit the ASCII code ST 0.
2. Press START/STOP button to off.
3. Press SELECT button to Son.
4. Press ARROW DOWN button to SoF.
5. Resume normal operation.

Direct Access Triggering (DAT)

Stanford Research Pulse Generator Setup

N E
ECESSARY QUIPMENT
• 1 ea. Delay Generator model #DG535
• 2 ea. Standard BNC cables
• 1 ea. 9 pin " D" connector, male
S
TEPS
1. Make up a special cable consisting of 2 BNC cables and a 9 pin D male.
• Label one of the BNC cables FIRE and the other Q-SWITCH.
• Take the FIRE and Q-SWITCH BNC cables and remove the connetor from one end
and expose the center conductor and shield.
• Solder center conductor of the FIRE BNC to pin 7 of the 9 pin D connector.
• Solder the shield of the FIRE BNC to pin 2 of the 9 pin D connector.
