Page 2: The Power Button
Your DiamondBoxx was hand-built, cared for properly it should provide you with many years of listening pleasure. Ok! Let's Play! The Power Button This controls the power to the DiamondBoxx. Push in to power on, push in again to power off. - Page 3 TWS (True Wireless Stereo) function. A quick press and release of the button will toggle the DiamondBoxx XL2 between SQ mode and SP mode. The indicator on the Mode switch will illuminate blue when in SP mode. Use the chart on next page to decide which...
- Page 4 MODE Best for Max SPL Batt life Normal 121* 4-25 hours Listening, (8-50 hours deep bass, w/ 462Wh best outdoor battery) bass When 124* 3-20 hours (Indicator maximum (6-40 hours LED blue) loudness is w/ 462Wh needed, battery) indoors if bass is overwhelming *Indoors in average sized room at 3 foot distance...
- Page 5 The MODE/TWS Switch - TWS function To wirelessly connect two 2 generation DiamondBoxx perform the following: 1. Power on the DiamondBoxx that will be the MAIN unit 2. Connect the Bluetooth device to it 3. Power on the DiamondBoxx that will be SECONDARY unit 4.
-
Page 6: Battery Life
Battery Life After a full recharge, the DiamondBoxx will play 3 – 50 hours depending on volume level, mode, music type and which battery option your DiamondBoxx has. Charging is accomplished by plugging in the supplied charger to the rear panel. DiamondBoxx CAN BE played while charging. - Page 7 If the item you want to plug in doesn't have the right jack, your local electronics store will have an adapter. Note: If using the DiamondBoxx as an audio amplifier for a video source, (watching movies and etc.) the AUX...
- Page 8 Self explanatory. Tip: We suggest if the music source being connected to the DiamondBoxx also has a volume control, leave that device's control at MAX volume. Use the DiamondBoxx volume control to control the level. This will provide the cleanest sound without Bluetooth or other random noise getting into the sound.
-
Page 9: The Rear Panel
USE ONLY THE INCLUDED CHARGER OR MAJOR DAMAGE CAN OCCUR, THE MODEL XL and XL2 USE A 7A 4 PIN CHARGER THAT IS DIFFERENT THAN MODEL M AND MODEL L CHARGERS. The OUT jack is for connecting to the IN jack of another DiamondBoxx Model XL2, XL, L2, or L. -
Page 10: Other Uses
If you really want to get crazy we suggest purchasing some DiamondBoxx replacement small feet from DiamondBoxx.com to screw into the sides of the DiamondBoxx so that they can be positioned vertically instead of horizontally. (These are the feet for the... - Page 11 1. Make sure nothing else / nobody else is connected to it. 2. Power off DiamondBoxx for 30 seconds, then power on and look for DiamondBoxx XL2 to pop up on your mobile device, tap to connect. 3. Make sure you are within 50 feet line of sight, closer if objects, walls, human bodies etc.
- Page 12 As they are all hand built and rolled it is normal for there to be slight inconsistencies in the finish. Consider them like beauty marks, specific to your DiamondBoxx. To clean just wipe down with a water dampened cloth. Happy Listening!
-
Page 13: Included Items
Internal Battery- Lithium Ion 231 or 462Wh Max Voltage- 16.8V Battery Life- Over 1000 recharge cycles Time to fully recharge- 3 - 6 hours Included Items DiamondBoxx Model XL2 Lithium Ion Battery Charger 3.5 mm stereo audio cable This manual... - Page 14 Limited Warranty DiamondBoxx warranties this product to be free of defects in materials and workmanship for a period of two years from the original purchase date.This warranty is not transferrable and applies only to the original purchaser from an authorized DiamondBoxx dealer.
- Page 15 To obtain service please e-mail DiamondBoxx at Info@DiamondBoxx.com...
- Page 16 DiamondBoxx Model XL2 Owner's Manual RevA 2018 Camarillo, California...
