DiamondBoxx XX4 Manual

Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XX4 and is the answer not in the manual?

Questions and answers

Related Manuals for DiamondBoxx XX4

Summary of Contents for DiamondBoxx XX4

  • Page 2 But your patience and our perseverance prevailed in the end. Thank you for putting your trust in DiamondBoxx. - Tony D’Amore Congratulations on your purchase of the highest performance portable Bluetooth speaker/amplifier system available.
  • Page 3 FUN FACT: You are now in an elite group of less than 100 people out of 8 billion that own a 10 Anniversary Edition DiamondBoxx XX4. Said another way, a person’s chance owning 0.0000000125%, Congratulations.

  • Page 4: The Power Button

    The Power Button This controls the power to the DiamondBoxx. Push into power on, push in again to power off. The Meters The meters are Tony D’Amore’s signature. He has been putting meters like this on products he has designed for the last 20 years.
  • Page 5 This is used for switching the backlight for the VU meters and the VU meters themselves off or on. We added this feature in case you want to use the XX4 in a low light situation It is also used for controlling the TWS (True Wireless Stereo) function.
  • Page 6 4. Press and hold the TWS button on Main DiamondBoxx until the LED under the letter “M” blinks rapidly, then release button. 5. Press and hold the TWS button on the Secondary DiamondBoxx until the LED under the letter “S” blinks rapidly, then release button.

  • Page 7: Battery Life

    Battery Life After a full recharge, the DiamondBoxx will play 4 – 30 hours depending on volume level, mode, music type and EQ settings. Charging is accomplished by plugging in the supplied charger to the rear panel. DiamondBoxx CAN BE played while charging. If the LED on the charger is RED, it is charging.
  • Page 8 The AUX IN jack This is a ZERO LATENCY input, perfect for using the DiamondBoxx XX4 with a video projector or other video source without lip-sync issues. The front panel AUX IN jack can be connected to just about anything with an audio output.

  • Page 9: The Control Panel

    SUBWOOFER LEVEL knob to the full counterclockwise position (7 o’clock). To get to know your XX4 we recommend setting all the knobs to 0, or the 12 o’clock position and then adjusting to taste. NOTE: Turning all the knobs all the way up will likely...
  • Page 10 It’s like virtual surround sound to use common marketing terms. After listening to your XX4 with the setting at halfway up or more, you won’t want to live without it.

  • Page 11: The Rear Panel

    We had to put side handles! The XX4 is such a beast, its easier to carry if you have a friend with you, so we put a handle on each side as well. The handles are not centered on the side panels, but rather centered on the center of gravity of the XX4.

  • Page 12: Other Uses

    If two Model XX4 are to be used in a LEFT and RIGHT stereo setup, use the TWS wireless function. If the 3.5mm jack method is used, both DiamondBoxxes will play stereo information themselves.
  • Page 13 Tip: We suggest setting the volume control on your mobile device to MAX and using the volume control on the DiamondBoxx to set the volume to your desired listening level for best performance. The Bluetooth range should be about 200 feet in line of sight.
  • Page 14 2. Power off DiamondBoxx for 30 seconds, then power on and look for DiamondBoxx XX4 to pop up on your mobile device, tap to connect. 3. Make sure you are within 200 feet line of sight, closer if objects, walls, human bodies etc.
  • Page 15 As they are all hand built it is normal for there to be slight inconsistencies in the finish. Consider them like beauty marks, specific to your DiamondBoxx. To clean just wipe down with a water dampened cloth.

  • Page 16: Included Items

    32Hz - 22kHz @+/ -3dB Weight 70 lbs. Internal Battery Lithium Ion, 4s6p or 4s12p Charging Voltage 16.8V Battery Life Over 1000 recharge cycles Included Items DiamondBoxx Model XX4 7A Lithium-Ion Battery Charger 3.5 mm stereo audio cable This manual...
  • Page 17 Limited Warranty DiamondBoxx warranties this product to be free of defects in materials and workmanship for a period of two years from the original purchase date. This warranty is not transferrable and applies only to the original purchaser from an authorized DiamondBoxx dealer.
  • Page 18 If you need service on your DiamondBoxx: All warranty returns should be sent to DiamondBoxx in the original packaging (so it doesn't get more damaged on its way to us) accompanied by proof of purchase (a copy of the original sales receipt).
  • Page 19 To obtain service please e-mail DiamondBoxx at Info@DiamondBoxx.com Happy Listening! Tony D'Amore DiamondBoxx...
  • Page 20 DiamondBoxx Model XX4 10 Anniversary Owner's Manual 2024 Camarillo, California...
