- Page 2 Class A/B high fidelity amplifier in a bi-amped arrangement with active crossovers for the best sound possible in the lightest package with the longest battery life. Your DiamondBoxx was hand-built and Cared for properly should provide you with years of listening pleasure. Ok! Let's Play!
-
Page 3: Battery Life
Battery Life After a full recharge, the DiamondBoxx will play for 4 - 20 hours with 115Wh battery or (8 - 40 hours with 231Wh battery) depending on volume level and music type. Charging is accomplished by plugging in the supplied charger to the rear panel. - Page 4 To USE TWS (True Wireless Stereo) System 1. Start with both DiamondBoxxes powered OFF. 2. Power up one of the DiamondBoxx, pair your Bluetooth device with it. Start streaming some music to it. 3. Power up the 2 DiamondBoxx 4.
- Page 5 5. Now go to the 2 DiamondBoxx, press and hold the TWS button until the Diamond starts flashing Green then release button. This will set this DiamondBoxx to “SECONDARY” speaker which will receive and play RIGHT audio only. 6. Wait minutes DiamondBoxxes to configure themselves and form a secure connection.
- Page 6 turns RED, this will CLEAR the TWS memory. Do this to both units and start procedure again from Step 1.
- Page 7 If this happens please plug charger into DiamondBoxx and let charge for a few minutes before expecting the DiamondBoxx to unmute and start playing music again.
- Page 8 The Knobs Your DiamondBoxx should have been delivered along with 3 more sets of knobs in other colors. This provides you with a way to customize your DiamondBoxx the way you want it.
- Page 9 The Volume knob is pretty Self explanatory. Tip: suggest if the music source being connected to the DiamondBoxx also has a volume control, leave that device's control at MAX volume an use the DiamondBoxx volume control to control the level. This will provide the cleanest sound with lowest background noise floor.
- Page 10 The Handle The handle was designed to make the DiamondBoxx portable while feeling good in your hand. It can lock in 2 positions. As with anything leather, it is a little stiff at first. A good pull on it should lock it in the upright position.
- Page 11 Putting things between like human bodies and walls will decrease this. Lifting the DiamondBoxx off the floor or ground will usually increase the range. If having trouble connecting, first check that another device isn’t already connected, this is usually the reason for connection troubles.
- Page 12 If DiamondBoxx M3 is already there, delete it. Now power DiamondBoxx watch DiamondBoxx M3 to pop-up on the device list. Select it and it should connect within 10 seconds. The DiamondBoxx Enclosure The enclosure is made from Medium Density Fiberboard (MDF).
-
Page 13: Included Items
Play time on full charge 8 to 40 hours Battery Life- Over 1000 recharge cycles Time to full recharge- About 8 hours Included Items DiamondBoxx Model M3 Lithium Ion Battery Charger 3.5 mm stereo audio cable Anodized aluminum knobs accessory pack This manual... - Page 14 Limited Warranty DiamondBoxx warranties this product to be free of defects in materials and workmanship for a period of two years from the original purchase date. This warranty is not transferrable and applies only to the original purchaser from an authorized DiamondBoxx dealer.
- Page 15 To obtain service worldwide please e-mail DiamondBoxx at Info@DiamondBoxx.com...
- Page 16 DiamondBoxx Model M3 Owner's Manual Rev 1 2019 Camarillo, California...
