ES-16-XG Quick Start Guide
Package Contents
EdgeSwitch
Mounting Screws (Qty. 4)
Installation Requirements
Phillips screwdriver (for rack- or wall-mounting)
Standard-sized, 19" wide rack with a minimum of 1U height available (for rack-mounting)
Use compatible fiber SFP+ modules with the appropriate fiber optic cabling. For
information about compatible fiber SFP+ modules, visit:
For indoor applications, use Category 6A (or above) UTP cabling approved for indoor use.
For outdoor applications, shielded Category 6A (or above) cabling should be used for all
wired Ethernet connections and should be grounded through the AC ground of the power
supply.
We recommend that you protect your networks from harmful outdoor environments and
destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For
more details, visit:
Note:
housed inside a protective enclosure.
https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]
ES-16-XG Quick Start Guide
Rack-Mount Brackets (Qty. 2)
ui.com/toughcable
Although the cabling can be located outdoors, the EdgeSwitch itself should be
Cage Nuts (Qty. 4)
ubnt.link/SFP_DAC_Compatibility
Bracket Screws (Qty. 8)
Power Cord

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EdgeSwitch ES-16-XG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ubiquiti EdgeSwitch ES-16-XG

Summary of Contents for Ubiquiti EdgeSwitch ES-16-XG

  • Page 1 Ethernet connections and should be grounded through the AC ground of the power supply. We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit: ui.com/toughcable...

  • Page 2: Hardware Overview

    The System LED functionality has been updated with firmware v1.8.0. We recommend that you update the EdgeSwitch to the latest firmware. System LED Flashing White Bootup in progress. Ready for use, not connected to Ubiquiti® Network White Management System (UNMS™). Blue Ready for use, connected to UNMS.
  • Page 3 ES-16-XG Quick Start Guide Link Established at 1 Gbps Green Flashing Indicates Activity Link Established at 10 Gbps White Flashing Indicates Activity RJ45 Speed/Link/Act LED (Ports 13 - 16) No Link Link Established at 1 Gbps Green Flashing Indicates Activity Link Established at 10 Gbps White Flashing Indicates Activity...

  • Page 4: Hardware Installation

    ES-16-XG Quick Start Guide RJ45 serial console port for Command Line Interface (CLI) management. Use an RJ45-to- DB9, serial console cable, also known as a rollover cable, to connect the Console port to your computer. Then configure the following settings as needed: Baud rate 115200 Data bits 8 Parity NONE...
  • Page 5 ES-16-XG Quick Start Guide https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...
  • Page 6 ES-16-XG Quick Start Guide https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...
  • Page 7 ES-16-XG Quick Start Guide Connecting Power Connecting SFP+ https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...
  • Page 8 ES-16-XG Quick Start Guide https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...

  • Page 9: Accessing The Configuration Interface

    ES-16-XG Quick Start Guide Connecting RJ45 Accessing the Configuration Interface The EdgeSwitch is set to DHCP by default, so it will try to automatically obtain an IP address. If that fails, then it will use the default fallback IP address, 192.168.1.2. Proceed to the https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...
  • Page 10 ES-16-XG Quick Start Guide appropriate section, DHCP or “Fallback IP Address”: DHCP Use one of the following methods: Set up the DHCP server to provide a specific IP address to the EdgeSwitch based on its MAC address (on the label). Let the EdgeSwitch obtain an IP address and then check the DHCP server to see which IP address was assigned.
  • Page 11 ES-16-XG Quick Start Guide 4. Enter ubnt in the Username and Password fields. Click Sign In. 5. The EdgeSwitch Configuration Interface will appear. Click the System Settings tab. 6. Change the IP Address to a unique IP address. Click Apply. https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...

  • Page 12: Specifications

    ES-16-XG Quick Start Guide Note: If you change the IP settings, then the session will be cut off, and you will need to reconnect to the EdgeSwitch using the new IP address. Customize additional settings as needed. For more information, refer to the EdgeSwitch documentation, which is available at ui.com/download/edgemax UNMS Management...

  • Page 13: Safety Notices

    ES-16-XG Quick Start Guide 25 to 16VDC Rack-Mount Yes, 1U High LEDs Per Port SFP+ Data Ports Speed/Link/Activity RJ45 Data Ports Speed/Link/Activity Interfaces Networking Interfaces (12) 1/10 Gbps SFP+ Ethernet Ports (4) 1/10 Gbps RJ45 Ethernet Ports Management Interface (1) RJ45 Serial Port, Ethernet In-Band ESD/EMP Protection Air: ±...

  • Page 14: Limited Warranty

    ES-16-XG Quick Start Guide intended for connection to a grounded safety outlet. a. Do not substitute the power cord with one that is not the provided approved type. Never use an adapter plug to connect to a 2-wire outlet as this will defeat the continuity of the grounding wire. b.

  • Page 15: Declaration Of Conformity

    ES-16-XG Quick Start Guide CE marking on this product represents the product is in compliance with all directives that are applicable to it. WEEE Compliance Statement Declaration of Conformity Online Resources © 2020 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/ES-16-XG/ES-16-XG_EN.html[3/20/2020 11:20:06 AM]...
