In this mode, the Genesis II Select Directional simultaneously
processes and displays the patrol and target motor vehicle speeds .
Detected target speeds will appear in the TARGET window . When
no targets are present, the TARGET window will show three dashes .
Patrol speeds will display in the PATROL window while the patrol
motor vehicle is moving .
5.5 Moving Mode Same Direction
To display the speed of targets traveling the same direction as the
patrol motor vehicle, use the Moving Mode Same Direction setting .
A patrol car tracking a target using Moving Mode Same Direction .
To select this mode, press and release the MODE button until the
MODE window shows two upward pointing arrows .
The MODE window when the radar is in Moving Mode Same Direction .
Unlike conventional moving radars, the operator is not required
to choose a "Faster or Slower" setting when measuring same lane
targets . The Genesis II Select Directional chooses the correct setting
automatically .
30
Figure 5.5a
Figure 5.5b
25/Aug/2010
WARNING
• When operating with the Directional Antenna, be
sure the antenna facing forward is connected into
the "FRONT" antenna port . If using dual antennas, the
antenna facing the rear should be connected into the
"REAR" antenna port .
5.6 Faster Mode
The FAST button activates the Faster Mode, modifying the operation
of the Stationary and Moving Mode Opposite Direction modes .
The Faster light illuminates when you press the FAST button on the
hand-held remote .
When activated, the system simultaneously displays the strongest
target signal and the next strongest target signal going faster than
the target signal .
In the figure below, the 99 km/h motor vehicle is the strongest target
if the FAST button is activated, then the next stronger faster target,
namely the passenger motor vehicle at 123 km/h will be displayed .
99 Km/H
OVERTAKING VEHICLE (123 Km/H)
RADAR PATROL VEHICLE (104 Km/H)
Figure 5.6
Evaluating multiple targets in Faster Mode .
25/Aug/2010
98 Km/H
107 Km/H
136 Km/H
31
