4. Operating Instruction.

4-1. Function:

remote control control, they can control
elevating stand to move 640mm from up to
down. (see diagram 8)

4-2. Remote Control

4-2.1. Key Function
1. Up : one push to extend elevating stand to the
top.
2. Down : one push to back elevating stand to the
bottom.
3. Left : hold on to raise elevating stand.
4. Right : hold on to lower elevating stand.
4-2.2. Operating Instruction
1. Aim the LED indicator (on remote control )at TV . The
remote range is 3 -10m.
2. Insert one 23A,12V battery in the remote control. If the
battery ran out , please open the battery cover and put in
new battery.
3. When user press any function key of remote control, the
TV bracket with TV will move to the corresponding place
,and will stop when you loosen the key.
4-2.3. Notice
If any remote control of our product was lost or damaged
,you can buy a new remote control and manual control with
the same frequency which produce by our company(For the
specific operation way, please see the attached user's guide
of manual control).

5. Technical Parameters:

Item TV Screen
Model Size (inch)
NY-13 32~42"
WARNING:
This wall mount is intended for indoor use only with the maximum weights indicated . Use with vier
than the maximum weights indicated may result in instability causing possible injury.
6. Caution:
This product has
(See diagram 9):
Cart Max Installation
Dimension Size (inch)
28.3"x 23.6 x 15.7
8.9"x38.6"
Min Installation Operating
Size (inch) Life (times)
7.87 x 7.87 30,000
USER'S GUIDE
L/R Extending
angle () Length(in) Weight (lbs)
± 15 25.2 60.63 ±1
Page 6
Net
