Notice 1: Use originals only,any other unapproved components may result in the falling off of TV
and this bracket.
Notice 2:Check all the parts included with shown in the manual. If parts are missed or damaged,do
not use it and please return to your local distributor.
1.3 Assembly tools (NOT INCLUDED)

2. Electric Specification

2-1. Input voltage/Current/Frequency, Output current

A. Input voltage/Current/Frequency: 110-240VAC/< 1.2A/50~60Hz
B. Output current: DC24V , 3A

2-2. Motor

Item
Motor
Warning:
1. Incorrect installation may result in fall off of TV and this bracket and personal injuries.
2. Wall or floor mounting of this bracket is out of the responsibility of manufacturer shall be carried
out by competent persons, or licensed person, with using the attached anchors (Ø10-M8x70)
only to ensure the safety.
3. Use this bracket properly, please read the instructions carefully before installation. Keep this
guide well for further reference.
4. The user must pay attention to the weight of TV and This product, and only solid wall (the
wall must be make up of concrete or brick) can support the weight . Please complied with the
installation instruction of LCD/PDP to install them.
5. Do not attach the TV on the bracket before installations.
6. Keep the knob at "Close" position before fully installation, on the other hand do not forget to
switch it to "Open" after installation is finished.
Rated
Current
Voltage
(No load)
DC24V
≤ 0.7 A
USER'S GUIDE
Current
(Rated load)
Temperature
≤ 1.8 A
-20 C ~ -50 C
Page 2
