Brooks Firetracker FT1-SB System Manual

Single zone fire alarm system
Hide thumbs Also See for Firetracker FT1-SB:
Table of Contents

Advertisement

Quick Links

Download this manual
SYSTEM MANUAL
FT1-SB
Single Zone
Fire Alarm System

Advertisement

Table of Contents
loading

Related Manuals for Brooks Firetracker FT1-SB

Summary of Contents for Brooks Firetracker FT1-SB

  • Page 1 SYSTEM MANUAL FT1-SB Single Zone Fire Alarm System...

  • Page 2: Document History

    FT1-SB System Manual MA370 Iss. 1 DOCUMENT HISTORY Issue Date Description Written By Checked By Draft 0 2/9/2008 Original Document. A. Shenouda C. Orr Issue 1 4/11/2011 Update drawing in figure 7 A. Shenouda A. Shenouda...
  • Page 3 FT1-SB System Manual MA370 Iss. 1 INDEX INTRODUCTION ........................4 Important Information ......................4 System Overview ......................... 4 Features ..........................5 OPERATION ..........................6 Front Display Module ......................6 Termination and Control Module ..................7 Power Supply ........................8 FT1-SB Indications ......................9 2.4.1 LED flash functions ......................
  • Page 4 FT1-SB System Manual MA370 Iss. 1 FIGURE LIST Figure 1 FT1-SB Display ........................6 Figure 2 FT1-SB Control & Termination Module ................7 Figure 3 Din rail Power supply ......................8 Figure 4 Typical Relay or Sounder Control Circuit ................11 Figure 5 Zone Input Circuit ......................12 Figure 6 FT1-SB Block Wiring Diagram ...........
  • Page 5 1 INTRODUCTION Important Information The Brooks Firetracker FT1-SB is single zone conventional fire alarm panel with compatible smoke and/or heat detectors and auxiliary devices, it provides a complete single zone automatic fire detection and alarm system. FT1-SB has been designed to comply with the Australian standard AS7240.2 and for specific use in non critical switchboard applications such as main...
  • Page 6 FT1-SB System Manual MA370 Iss. 1 Features The Brooks FT1-SB utilizes the leading edge technology: • Microprocessor based system in both display and termination modules. • Easy to install, standard meter enclosure DIN rail termination module and power supply •...

  • Page 7: Operation

    MA370 Iss. 1 OPERATION Front Display Module The front display of Brooks FT1-SB is shown in Figure 1. Figure 1 FT1-SB Display The front display of FT1SB compromises indicators and controls for all system functions. The alarm zone facility is segregated and includes a separate control and LED indicator for each function, i.e.
  • Page 8 MA370 Iss. 1 Termination and Control Module The Termination & Control Module of Brooks FT1-SB is shown in Figure 2. Figure 3 FT1-SB Termination & Control Module The control and termination module should be mounted on a DIN rail installed at a convenient location within the switchboard cabinet.
  • Page 9 FT1-SB System Manual MA370 Iss. 1 Power Supply Brooks FT1-SB is powered by a DIN rail switch mode power supply as shown in Figure 4 below Figure 4 Din rail Power supply Features: • Universal AC input • Short circuit / Overload / Over voltage Protections •...
  • Page 10 FT1-SB System Manual MA370 Iss. 1 FT1-SB Indications The default state of the LED indicators and the buzzer is OFF if it is not defined below. 2.4.1 LED flash functions The FT1-SB LED indicators use the following flash pattern to signal the system conditions. Table 1 FT1-SB LED Indicating Patterns Indicators Pattern...

  • Page 11: Control Functions

    FT1-SB System Manual MA370 Iss. 1 2.4.3 Control Functions Table 3 FT1-SB Control Buttons Control Condition Description Silences the panel buzzer until a new fault or Buzzer Mute Buzzer Off alarm occurs Reset active alarm or fault Disable active test mode. Reset System resetting Note: If alarm or fault condition still active,...
  • Page 12 FT1-SB System Manual MA370 Iss. 1 Supervised Output FT1-SB provides one supervised output protected with 1 Amp fuse. External relays, sounders, or strobes, shall be connected as shown in Figure 5 Figure 5 Typical Relay or Sounder Control Circuit If the supervised output is not used, the EOL resistor shall be installed on the output terminals on the control / termination module.
  • Page 13 FT1-SB System Manual MA370 Iss. 1 Table 5 Compatible Actuating Devices Part No. Manufacturer Description 4350 Panasonic Conventional multi detector 4352 Panasonic Conventional photoelectric smoke detector 6295 Panasonic Conventional enclosed heat detector 60 degrees 6296 Panasonic Conventional enclosed heat detector 80 degrees 6297 Panasonic Conventional enclosed heat detector 100 degrees...
  • Page 14 FT1-SB System Manual MA370 Iss. 1 FT1-SB Specification Table 6 FT1-SB General Specifications Feature Specification Input 85-264V AC, 120-270VDC Mains Power Supply Output 24VDC adjustable +/- 10%. 20 Watt, 1Amp Nominal 50mA Current Consumption Alarm 150mA Cable Length Up to 3 metres (between display &...

  • Page 15: Installation And Commissioning

    This chapter provides the CIE installation and commissioning guidelines. The installation and the commissioning of Brooks FT1-SB shall be carried out in accordance of AS3000. For detector selection and location refer AS1670.1 2004 Appendix A. The block wiring diagram of FT1-SB is shown in figure 7 DET.
  • Page 16 FT1-SB System Manual MA370 Iss. 1 Figure 8 Control / Termination Module & Power Supply mounting Rear Front Figure 9 FT1-SB Front Display typical mounting...

  • Page 17: Visual Inspection

    FT1-SB System Manual MA370 Iss. 1 3.1.2 Wiring The wiring of FT1-SB shall be according to the block wiring diagram shown in figure 7. 3.1.3 Visual inspection Full functional testing and visual check have been carried out in the factory before despatching the FT1SB System.
  • Page 18 FT1-SB System Manual MA370 Iss. 1 3.2.3 Actual Test Alarm Test 1. Using an aerosol smoke simulation spray, spray each smoke detector in turn and check the following: • Alarm LED illuminates steady • Buzzer is steady On • Alarm relays on the Control / Termination Module are energized •...

  • Page 19: Product Guarantee

    No other guarantees written or verbal are authorised to be made on behalf of Brooks. All other conditions and warranties whether expressed or implied are, to the extent permitted by law, hereby excluded.

  • Page 20: Regional Offices

    New South Wales / Australian Capitol Territory 4 Pike Street, Rydalmere. 2116 Phone: 61 (0)2 9684 1466 Facsimile: 61 (0)2 9638 7700 E-mail: sales@brooks.com.au Regional Offices Victoria / Tasmania 1/3 Molan Street, Ringwood 3134 Phone: 61 (0)3 9879 5294 Facsimile: 61 (0)3 9879 5249 E-mail: salesvic@brooks.com.au...
