- Page 1 User Guide DVI / HDMI Fiber Optic Cables DVI-23xxx-FO...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE PRODUCT SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 PRODUCT LIABILITY . -
Page 3: Product Safety
Every effort has been made to ensure that this product is free of defects. DVIGear cannot be held liable for the use of this product or for any direct or indirect consequential damages arising from its use. It is the responsibility of the users of this product to check that it is suitable for their requirements and that it is installed correctly. -
Page 4: Introduction
Our digital video distribution products have been serving the professional AV industry for more than fifteen (15) years. Today, DVIGear offers a full range of high performance products including: scalable AV-Over-10GbE Systems, Switchers, Splitters, Scalers, Up/Down/Cross-Converters, Format Converters, as well as a wide range of long-reach Digital Cables, Extenders, and Fiber Optic Transmission systems. -
Page 5: Specifications
2 .0 SPECIFICATIONS Performance Compliance DVI v1.0, HDMI v1.3, HDCP Maximum Pixel Clock Frequency 165 MHz Maximum Video Bit Rate 1.65 Gbps (Single-Link DVI) Supported Color Depth 8-bit Supported HDTV Formats 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, and 2048x1080 Supported PC Resolutions Up to 1600x1200 and 1920x1200 Digital Audio Support HDMI v1.3... -
Page 6: Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number and Invoice Number available for reference when you call. - Page 7 The cable material provides a high degree of ruggedness and flexibility and consists of 4x high-speed glass optical fibers and 6x copper wires. Note that the video signals travel over the glass fibers and are UNIDIRECTIONAL. The other signals (DDC, HPD, power, etc.) travel over the copper wires. Warning: This cable will not function if it is installed backward.
-
Page 8: Operating The Unit
5 .0 OPERATING THE UNIT Source Device (e.g. PC or Mac) DVI-23xxx-FO Fiber Optic Cable up to 100m Transmitter Module (Computer) Receiver Module (Monitor) AC Power Adapter (optional) Display Device (e.g. Projector) 5 .1 Interconnections Connect the transmitter module (labeled “Computer”) to the source device (e.g. - Page 9 5 .2 Optional AC Power Adapter The DVI / HDMI Fiber Optic Cables can be powered by the source device, provided it can supply sufficient current to the cable via the 5V power pin on the DVI or HDMI connector. The cable requires ~350 ma of DC current to energize the electronics in both the transmitter and receiver modules.
-
Page 10: Troubleshooting
If the problem persists after trying the above suggestions, please contact your dealer for additional assistance. If the dealer’s technical personnel are unable to assist you, please contact DVIGear via telephone at 1.888.463.9927 (toll-free for United States and Canada) or 1.770.421.6699. You may contact DVIGear by e-mail at support@dvigear.com. -
Page 11: Limited Warranty
In no event shall DVIGear be responsible or liable for any damage arising from the use of such defective products, including but not limited to loss of use, revenue or profit, whether such damages are direct, indirect, consequential or otherwise and whether such damages are incurred by the reseller, end user, or any third party. - Page 12 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 770.234.4207 Marietta, Georgia 30062-2258 www.dvigear.com DVI-23xxx-FO-UG-05 / July.2018...
