- Page 1 User Guide DVI-5312b DVI 1x2 Splitter / Repeater DVI-5314b DVI 1x4 Splitter / Repeater...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE PRODUCT SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 PRODUCT LIABILITY . -
Page 3: Product Safety
Every effort has been made to ensure that this product is free of defects. DVIGear cannot be held liable for the use of this product or for any direct or indirect consequential damages arising from its use. It is the responsibility of the users of this product to check that it is suitable for their requirements and that it is installed correctly. -
Page 4: Introduction
Our professional digital distribution products have been serving the industry for over ten (10) years. DVIGear offers a full line of high quality Digital Matrix Routers, Switchers, Splitters, Video Scalers, Up/Down/Cross Converters, Format Converters, Analog-Digital Converters, as well as a wide range of long reach Digital Cables, Extenders, and Optical Transmission systems. -
Page 5: Specifications
+10 dB correction @ 825 MHz Maximum Input Cable Length 12.5 meters using DVIGear SHR™ Series copper cables Maximum Output Cable Length 10 meters using DVIGear SHR™ Series cables, longer if using DVIGear (ACE™) Input /Output Connectors Input 1x 29-pin female DVI connector... -
Page 6: Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number, and Invoice Number available for reference when you call. -
Page 7: Operating The Unit
5 .0 OPERATING THE UNIT To use the DVI-5312b and DVI-5314b splitters, first connect a DVI-D or a HDMI- DVI cable from the DVI or HDMI source device to the input of the splitter. Next, connect the outputs of the splitter to their destination devices (typically displays or projectors). - Page 8 5 .1 EDID Management EDID (Extended Display Identification Data) is a collection of data cached inside all modern displays that describes the unit’s capabilities. The EDID information is defined by a standard published by the VESA (Video Electronics Standards Association) and includes information such as the manufacture’s name, model number, supported resolutions and video timings, supported audio formats, color space, etc.
- Page 9 Output #1, then Output #2, etc. The splitter will select the EDID from the first HDMI v1.3 compatible display that it finds. If no such displays are connected to the splitter, it will select the first EDID that it finds from a connected display that is HDMI v1.2 compatible.
-
Page 10: 6 .0 Troubleshooting
HDCP Repeater functionality. Note: For troubleshooting HDCP links, it can be very helpful to have a test generator that can turn HDCP On and Off manually. DVIGear’s DVI-7050a HDMI Test Generator is a good solution for this requirement. -
Page 11: Limited Warranty
(1) year from the date of purchase. Should this product, in DVIGear’s opinion, prove defective within this warranty period, DVIGear, at its option, will repair or replace this product without charge. - Page 12 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 770.234.4207 Marietta, Georgia 30062-2258 www.dvigear.com DVI-5312b_DVI-5314b_UG-04 / June.2012...
