- Page 1 VEO-SWM45 SWITCHER 4K 5x1 presentation switcher with HDBaseT extender USER MANUAL...
-
Page 2: Table Of Contents
INDEX IMPORTANT REMARK ......................4 IMPORTANT SAFETY INSTRUCTIONS ................4 IMPORTANT NOTE ........................ 6 INTRODUCTION ........................6 PACKAGE CONTENTS ......................7 PANEL DESCRIPTIONS ......................7 6.1. Frontal Panel ..........................7 6.2. Rear Panel ............................ 8 OSD MENU ..........................10 7.1. Picture mode User ........................11 7.2. - Page 3 8.2. Power rebooting ........................19 7.3. Signal removing ........................19 HDBT Receiver ........................20 10. CONNECTIONS ........................21 10.1. Connection diagram ......................21 10.2. VGA/YPbPr/CVBS input ...................... 22 10.3. Connection of microphones and line sources ............... 22 10.3.1. 48V mode ......................... 22 10.3.2.
-
Page 4: Important Remark
1. IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 5 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
-
Page 6: Important Note
3. IMPORTANT NOTE Thank you for choosing our VEO-SWM45 switcher. It is VERY IMPORTANT to carefully read this manual and to fully understand its contents before any connection in order to maximize your use and get the best performance from this equipment. -
Page 7: Package Contents
Support PCM stereo pass-through Touch Panel buttons, Embedded Web GUI, IR Remote, Logic contacts and RS- 232 control 5. PACKAGE CONTENTS 1 x HDMI 5x1 4K Presentation Switcher 1 x HDbaseT Receiver 2 x Mounting Ears ... -
Page 8: Rear Panel
1. CONTROL Ports: o LAN Port: This port is the link for Web GUI and Telnet control. o RS232 Port: Serial control port suitable for controlling the VEO-SWM45 switcher or any third party device connected to the HDbaseT receiver. o IR Input Port: Connect the provided IR Receiver cable. It allows sending IR commands to a remote device through the HDbaseT extender IR Out port. - Page 9 o Contact IN: This ports allow to select a source closing the corresponding dry contact to the GND pin (marked as ), as reported on the following table: Pin number Source Pin 1 HDMI1 Pin 2 HDMI2 Pin 3 HDMI3 Pin 4 DisplayPort Pin 5...
-
Page 10: Osd Menu
6. DC 24V Power Connector: Plug the included 24VDC power supply. 7. OSD MENU The VEO-SWM45 provides a user friendly OSD operation menu. Press the MENU button on the IR remote controller or on the frontal panel to enter the main menu and configure the switcher. -
Page 11: Picture Mode User
7.1. Picture mode User This option allows improving the picture quality adjusting the following parameters: Contrast 0-100 (Default 50) Brightness 0-100 (Default 50) Colour 0-60 (Default 30) Sharpness 0-20 (Default 10) Tint 0-100 (Default 50, for CVBS and NTSC format only) 7.2. -
Page 12: Screen
7.3. Screen The screen menu affects the VGA input only. The user can adjust Horizontal position, Vertical Position, Clock and Phase. 7.4. EDID Settings The EDID MENU adjusts will affect HDMI and DisplayPort inputs only. -
Page 13: Audio Setup
The different EDID options will allow the sources devices to negotiate their output resolution as reported on the following table: EDID1.4 4K2K30,PCM 2.0 EDID2.0 4K2K60,PCM 2.0 EDID From HDMI EDID copy from local HDMI port EDID From HDBT EDID copy from HDBaseT Receiver HDMI port EDID AUTO Auto compare HDMI and HDBT Receiver HDMI port EDID and select the highest common resolution... -
Page 14: Network Setup
7.6. Network setup The Network Setup MENU reports all the network settings. Through this menu it is possible to set up the switcher as DHCP client or assign it a static IP address: 7.7. System Setup The system setup menu includes the followings sub menu: Output Resolution, Output HDCP, Sleep Timer, OSD time out, RS-232 Baud Rate, Test Pattern and Factory reset. -
Page 15: Resolution
7.7.1 Resolution The VEO-SWM45 HDMI output resolutions support multiple modes. The resolution in use can be changed using the system setup menu or pressing the “RES” button on the IR remote. The user can force a custom output resolution for its own HDTV or Monitor. -
Page 16: Hdcp On Out
7.7.2. HDCP on out Set the HDMI and HDBT port output HDCP status. Pass through means the output HDCP follows the selected input source HDCP version. HDCP1.4 means the output HDCP will fix to version 1.4. 7.7.3 Sleep timer The switcher sleep time is the time since the switcher detects no signal coming from the selected source and the standby mode. -
Page 17: Osd Time Out
7.7.4 OSD time out Set the OSD display time, default time is 10 seconds. 7.7.5 Baud Rate Set the switcher RS-232 control port baud rate. The default value is 115200bps. -
Page 18: Test Pattern
Selecting the factory default option all the switcher parameters will be returned to factory default (HDMI input 1, audio mixer on, Output resolution set to 1920x1080 @60Hz, Baud rate set to 115200 bit/s etc.). 6.8 Software update About this session, please contact www.ecler.com for further instructions. -
Page 19: Auto-Switching Function
VEO-SWM45 includes auto-switching and manual-switching modes. When auto- switching mode is active, the switcher will act as follows: 8.1. New Input Once a new input signal is detected, VEO-SWM45 will switch to this new signal automatically. 8.2. Power rebooting Once the unit is switched on, the last signal used before powering it off it will be automatically selected. -
Page 20: Hdbt Receiver
3. HDBaseT Input Port: Connect it through a CAT5e-CAT7 standard cable to the VEO-SWM45. This link will provide AV and control signals to the receiver and it allows to power supply it from remote without the need of any external PSU. -
Page 21: Connections
10. CONNECTIONS 10.1. Connection diagram... -
Page 22: Vga/Ypbpr/Cvbs Input
10.2. VGA/YPbPr/CVBS input The VGA input port is a multiple format port. It supports VGA/YPbPr/CVBS input signal. The switcher will auto detect the input signal type and format. The user can use the convert cable for YPbPr or CVBS signal input. 10.3. -
Page 23: Mic Mode
10.3.2. MIC mode When switched to “MIC” the microphone input is used for connecting dynamic microphones and electrets condenser microphone. Unbalanced connection: “-” and “ ” connect to ground, and “+” connects to signal. Balanced connection: “+” connects to positive, “-” connects to negative and “ ”connects to ground. -
Page 24: Line Mode
10.3.3. Line mode When switched to “LINE” the microphone input is used for connecting line level signals coming from paging systems or wireless microphones. Unbalanced connection: “-” and “ ” connect to ground, and “+” connects to signal. Balanced connection: “+”... -
Page 25: Remote Control And Ir Operations
11. REMOTE CONTROL AND IR OPERATIONS 11.1. Remote Control 1. Power: Press this button to power on the switcher or for setting it to standby mode. 2. ADJ: Press this button for operating VGA input auto adjustment function; 3. INPUT: Press these buttons for selecting the input sources. -
Page 26: Control Local Device From Remote
10.2.2. Control local device from remote Control a local source device from remote using its corresponding remote controller. IR (20KHz-60KHz) cable connections... -
Page 27: Rs-232 And Telnet Control Operations
A bi-directionally RS-232 communication can be established between the switcher and the HDBaseT receiver to control a third party RS-232 device (tunneling) or to directly control the VEO-SWM45 switcher with a third party control system. 12.1. Control the Switcher or 3rd Party Device from Local... -
Page 28: Rs-232 Controller
12.3. RS-232 Controller VEO-SWM45 can be controlled by a third party control system or it can act as RS232 pass-through extension. For testing purposes, a serial terminal software can be used (e.g. Hercules,Putty..). Please connect the switcher to a PC/Mac with a serial terminal software installed. -
Page 29: Rs232 Communication Commands
12.4. RS232 Communication Commands Item Command Description help! Display all communication commands s factory reset! Return to factory reset setting r version! Read current FW version xyz! Upgrade the switcher FW r power! Read the switcher power on/off status s power on! Power on the switcher s power off! Power off the switcher... - Page 30 Setup output resolution at 3840x2160@30Hz (1:3840x2160@30Hz,2:3840x2160@25Hz, 3:1920x1080@60Hz,4:1920x1080@50Hz, 5:1280x720@60Hz,6:1280x720@50Hz, s output 1! 7:1920x1200@60Hz,8:1680x1050@60Hz, 9.1400x1050@60Hz,10.1360x768@60Hz, 11.1280x800@60Hz,12.1024x768@60Hz, 13.Out display EDID native resolution r hdcp! Read HDMI/HDBT output hdcp enable status s hdcp bypass! Set HDMI/HDBT output to hdcp pass through mode s hdcp 1.4! Set HDMI/HDBT output to hdcp1.4 version r contrast! Read picture contrast status...
- Page 31 Set output horizontal over scan to (100+X)%(the default X value is 0 and the range is -10~10,the value is set for current s h size X! input source. ) r v size! Read current input source output vertical overscan value Set output vertical over scan to (100+X)%(the default X value is 0 and the range is -10~10,the value is set for current input s v size X!
- Page 32 s mixer off! Setup mic mixer off s mixer auto! Setup mic mixer auto s auto vol! Set source audio volume when set to mixer auto mode r auto vol! Read source audio volume when set to mixer auto mode r fade in time! Read source audio fade in time when set to mixer auto mode Setup source audio fade in time when set to mixer auto...
- Page 33 r hdmi1 audio! Read HDMI1 audio source Choose audio source as HDMI1 audio input s hdmi1 auido 0! (0: Emb,1: Ext1,2: Ext2,3:Ext3,4:Ext4,5:Ext5) r hdmi2 audio! Read HDMI2 audio source Choose audio source as HDMI2 audio input s hdmi2 auido 0! (0: Emb,1: Ext1,2: Ext2,3:Ext3,4:Ext4,5:Ext5) r hdmi3 audio! Read HDMI3 audio source...
-
Page 34: Web Gui Control
Telnet terminal, open a connection using the switcher IP address and the port indicated on Network Settings. 13. Web GUI Control The switcher can be controlled via Web just digiting the VEO-SWM45 IP address on a web browser. If the IP address is unknown,... -
Page 35: General Page
In the address bar of the web browser to open the control GUI. As a web based GUI, it can be managed also via Mobile devices. If the VEO-SWM45 is connected to a wireless network, the presenter can control the switcher through his own mobile device if the devices are connected to the same WI-FI network. -
Page 36: Video Page
13.2. Video page 13.3. Audio page... -
Page 37: Network Page
13.4. Network page 13.5. Advanced page... -
Page 38: Application Diagram
14. APPLICATION DIAGRAM... -
Page 39: Technical Specifications
