8. Receiver encoding

A transmitter and receiver, which can be found in a single original box, have been
pre-set in the factory to use thus their encoding is not necessary.
If needed, the encoding steps described below must be followed:
1. Press and hold for 5 sec. the FUNCTIONS button - the memory will reset -
a blue and red diodes will lit at the same time. Once the memory is cleared, a
red diode INTERFERENCES will flash.
2. Press and hold for 1.5 sec. the FUNCTIONS button - the receiver will go to
a standby mode waiting for a code to be introduced - a blue and red diodes
will be flashing alternately.
3. At that time, a TEST function must be called on the DK LOGIC 200
transmitter. A code will be directed to a receiver: two diodes blue and red will
blink twice at the same time.
4. Next, a short communication test will be made - the RE1 relay will be
connected twice and an orange diode will be lit.
5. The transmitter and receiver set has been properly configured.

9. Interferences - communication error

Radio wave interferences may occur sporadically,
which can lead to a lack of communication
between the receiver and the transmitter. If this
happens, a red INTERFERENCES diode starts to
blink on a receiver and an Err1 message will be
displayed on the transmitter screen.
To restore communication follow the steps
described in the encoding process - see point 8
Receiver encoding.
