Summary of Contents for Samsung AR TSEC Series
- Page 1 Air conditioner Quick Guide AR**TSEC*** / AR**TVFC*** • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-08673A-00...
- Page 2 STEP 1 Check the model name. STEP 1 Check the model name. STEP 2 Go to the Samsung website (http://www. STEP 2 Contact Service Centre. samsung.com) or Read the QR code. STEP 3 Ask for the user manual of your product model.
-
Page 3: Indoor Unit Overview
Indoor Unit Overview The appearance of the actual product may differ slightly from the image below. 01 Air intake 06 Airflow blade (left and right) 02 Air filter 07 Power button/Remote control receiver 03 Tri-care filter (For AR**TSEC*** Models) 08 Room temperature sensor 04 Wind-Free panel 09 Display 05 Airflow blade (up and down) -
Page 4: Functions And Buttons
Operating the Air Conditioner Functions and Buttons Function Button and Selection Display Power On/Off Wind-Free In Cool/Dry/Fan mode ▶ Cooling AI Auto ▶ ▶ Select Auto. Auto ▶ ▶ Select Auto. Cool ▶ ▶ Select Cool. ▶ ▶ Select Dry. ▶... - Page 5 Function Button and Selection Display In operation ▶ ▶ Wi-Fi (SmartThings) Hold down 4 seconds. Electricity In operation ▶ ▶ ▶ consumption Select Usage. ▶ check In Cool or Heat mode ▶ ▶ ▶ Select Eco. ▶ ▶ Select On or Off ▶ (Set the duration.) ▶...
-
Page 6: Auto Clean Function
Cleaning Auto clean function Use the Auto clean function if the indoor unit produces odors. Activating Auto clean To activate Auto clean, press the (Options) button for at least 3 seconds. The indoor unit display shows: Canceling Auto clean To cancel Auto clean while it is running, follow the procedure below: ▶... - Page 7 1 Slide the filter off of the unit. 2 Use a soft brush or vacuum cleaner to remove any dust or debris on the filter. 3 Soak the filter in a solution of water and mild detergent for 30 minutes. 4 Rinse the filter and let it air dry in a well-ventilated area that is out of direct sunlight.
-
Page 8: Technical Specifications
Technical Specifications MODEL AR18TSECCWK/MG AR24TSECDWK/MG CLIMATES CLASS 17500 Btu/h 15300 Btu/h 20500 Btu/h 17500 Btu/h COOLING 5.13 kW 4.50 kW 6.00 kW 5.13 kW CAPACITY HEATING (H1) 6000 W 7100 W RATED VOLTAGE & FREQUENCY 230 V ~ 60 Hz 230 V ~ 60 Hz COOLING 6.6 A... - Page 9 Technical Specifications MODEL AR18TVFCGWK/MG AR24TVFCGWK/MG CLIMATES CLASS 17000 Btu/h 15300 Btu/h 20000 Btu/h 17000 Btu/h COOLING 5.01 kW 4.50 kW 5.88 kW 5.01 kW CAPACITY HEATING (H1) RATED VOLTAGE & FREQUENCY 230 V ~ 60 Hz 230 V ~ 60 Hz COOLING 7.0 A 8.0 A...
- Page 10 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.samsung.com/sa_en/support (English) SAUDI ARABIA (+966) 8002474357 (800 24/7 HELP) www.samsung.com/sa/support (Arabic)
