Cooper Lighting Corelite JAYLUM Installation Manual

INSTALLING FIXTURES
1 Fold in tabs for corresponding
mounting method.
Hang Fixture on MOUNTING BRACKET
2
and secure with included fasteners.
Pull wires from J-Box thru end of xture
for easy wiring while xture is hanging.
Wire xture to requirements following all
3
National and Local Electrical Codes.
Tuck wires back into xture.
ROW MOUNTING
1
Remove Top Lens and Re ector
2
Using provided Hardware secure xtures to MOUNTING BRACKET,
and connect xtures together as shown.
Make electrical connections and tuck wires into wire cavity
prior to hanging xture on mounting bracket.
3
Re-Install Re ector and Top Lens
A
B
Fold Tab A if xture to be joined to another xture (row).
C
Fold Tabs B and C if xture to be mounted as single unit
or if xture is at end of row.
See Page 1 Mounting Bracket Speci cations and Dimensions.
TOP LENS
#10-32 Nut
#10 Star Washer
JAYLUM INSTALLATION
WALL LED Luminaire
REFLECTOR
#10-32 Screw
Hardware should be positioned
at bottom of keyhole slot and
tightened securely.
ADE130028
