QUICK START GUIDE
Pressure on
- For positive range, never
exceed
8 bar
- For negative range, never
connect any positive pressure
Pressure supply
Flow EZ
The
TM
needs an external pressure
supply to operate. This can be
a lab's compressed air supply,
an air compressor, or any
clean (filtered < 10 µm) and dry
compressed air supply.
Flow EZ
Different
require different supply
pressures (shown to the right).
Note : If one intends to use compressed gas other than air, or if the pressure
supply is out of the pressure range requirements, please contact Fluigent.
(120 psi)
Push-Pull
or
ranges
TM
Always wear safety protection
when manipulating pressure.
Flow EZ Required pressure
TM
range (mbar)
7000
2000
1000
345
69
25
-25
-69
-345
-800
supply (mbar)
7100
2100
1100
150
-800
