QUICK START GUIDE
An overview of pressure-based microfluidic control
2
1
1
Supplied (inlet) pressure
2 Power supply
3 Regulated (outlet) pressure
4
Pressurized reservoir
5
Microfluidic set-up
The Flow EZ
1.
(inlet) pressure to a user -defined pressure with high precision.
This regulated (outlet) pressure pressurizes the reservoir,
2.
driving the liquid up through the tubing and into the
microfluidic set up.
3. Controlling the outlet pressure allows one to control the rate
at which fluid is injected into the microfluidic set up.
3
from pump or compressed air supply
to the Flow EZ / Push-Pull pressure controller
TM
from pressure controller to reservoir
P-CAP
in example a microfluidic chip
/ Push-Pull regulates the externally supplied
TM
4
5
3
