Summary of Contents for SONIQ Qvision LCDTV20
-
Page 2: Table Of Contents
TABLE OF CONTENTS Packing List ..............1 Safety Precautions ............2 Feature Description ............4 Identification of Controls ..........5 Preparing the Remote Control ......... 7 Connecting to the antenna..........8 General Function ..............9~12 Troubleshooting Guide............12... -
Page 3: Safety Precautions
USER MANUAL LCDTV20 BEFORE YOU BEGIN... Congratulations! You have purchased a Digital Television, one of the finest Color Televisions on the market today. This manual will guide you in the use of the many exciting features found on Digital televisions. These features will enhance your viewing experience, making your television viewing more enjoyable than ever before. - Page 4 USER MANUAL LCDTV20 6.Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.Never spill liquid of any kind on the product.
-
Page 5: Feature Description
USER MANUAL LCDTV20 BEFORE YOU BEGIN...(continued) Feature Description 20.1"TFT LCD Screen No Radiation, No Flash, Environmental Protection Slim, Light, Low-consumption RF Input Specified with CATV Features AV Input - VIDEO/S-VIDEO/SCART input available for convenience to enjoy various programs by video recorder, camera, player, etc. Built-in Speaker - dual channel stereo PAL/SECAM Mode Auto Volume Control... -
Page 6: Identification Of Controls
USER MANUAL LCDTV20 IDENTIFICATION OF CONTROLS Main unit (front view) 1.STANDBY Turns the TV On or Off 2.CH+ Used to select a channel up 3.CH- Used to select channle down 4.VOL+ Volume up 5.VOL- Volume down 6.TV/AV Used to select a signal sorce TV.A.S-video 7.MENU Accesses or banish the TV menu 8.LED Stand By indicator Video Input... - Page 7 USER MANUAL LCDTV20 IDENTIFICATION OF CONTROLS(continued) Remote Control Programme (Ch) Up Power Select Input Signal Enter the Menu System Volume Down Volume Up Programme (Ch) Down No Function No Function Display Channel Picture Preset Information Mute Numeric Buttons Timer Returns to previously selected channel Scans through the channels Sound Preset...
-
Page 8: Preparing The Remote Control
USER MANUAL LCDTV20 PREPARING THE REMOTE CONTROL To operate the LCD TV, you must first place the batteries in the remote control. 1. Open the cover. 2. Insert batteries (AAA size). Make sure to match the + and - on the batteries to the marks inside the battery compartment. -
Page 9: Connecting Tothe Antenna
USER MANUAL LCDTV20 CONNECTING TOTHE ANTENNA Impedance adapter Parallel flat:cable (300Ω-75Ω) (300 Ω) RF Input Coaxial cable (75Ω) To ensure best receiving effect, use outdoor antenna or cable antenna (CATV).The type and location of antennas shallvary with places. Notes: * Connect the outdoor antenna as shown above, and also install a lightning arrester and perform periodical checking and repair. -
Page 10: General Function
USER MANUAL LCDTV20 FUNCTIONS & FEATURES General Function 1.Turn “On/OFF” unit Connect AC/DC adaptor into unit (DC SUPPLY INPUT), before plug in AC wallet. STANDBY indicator on front panel will be “ON” in RED color, unit getting standby mode automatically.Press STANDBY button on Unit/Remote Control, unit will be “ON”, STANDBY indicator will be changed from RED to GREEN color. - Page 11 USER MANUAL LCDTV20 FUNCTIONS & FEATURES ... (continued) Function Selection Menus Easy OSD message is designed for setup each item adjustment, press MENU button to access the main menu; press CH+/CH-/VOL+/VOL- (direction keys) to navigate the items on menu with item highlighted; press VOL+/VOL- for adjustment.
- Page 12 USER MANUAL LCDTV20 FUNCTIONS & FEATURES ... (continued) confirm. *Save: To save the desired channel/system by using VOL + at this mode. Channel number will bem flash once for confirm. *Skip: Press VOL + or VOL- to turn skip function ON for the desired channel; To release the skipped channel, input the channel number, then press VOL + or VOL- at Skip mode to turn it OFF.
-
Page 13: Troubleshooting Guide
USER MANUAL LCDTV20 AV MODE (SC Video, SC RGB, VIDEO) Config Only 3 function classification on the above AV modes: Bright 1. Image Adjustment factors Contrast 2. Audio adjustment factors Color 3. Configure sharpness Operation for above (1, 2, 3) are same as TV Mode. TROUBLESHOOTING GUIDE Check the following guide for a possible correction to a problem before contacting customer service.
