Fire Safety; Smoke Alarms - Envirovent PIV AIR SOURCE Installation Manual

Fire Safety

Smoke Kits
For installations with a floor more than 4.5m above ground, a
compatible smoke kit must be fitted. The kits listed below contain
all the extra parts and instructions required:
Order Code
KIT-PIV-SMOKE-125
KIT-PIV-SMOKE-150
KIT-PIV-SMOKE-200
KIT-MIV-SMOKE-125

Smoke Alarms

For installations with a floor more than 4.5m above ground, the unit
must be wired into a smoke alarm in order to switch the unit off upon
the detection of smoke.
The unit can be wired into an existing smoke alarm (check compatibility
with the smoke alarm manufacturer). All wiring should be completed
by a competent person.
15
PIV & MIV Air Source / Inline
Description
PIV smoke kit with 1x 125mm diffuser
PIV smoke kit with 1x 150mm diffuser
PIV smoke kit with 1x 200mm diffuser
MIV smoke kit with 2x 125mm diffusers
SHOULD YOU ENCOUNTER ANY PROBLEMS
INSTALLING THIS UNIT, CALL US ON:
01423 859 395
