Vortex High Country Quick Start Manual page 2

Extending the leg length
Each tripod leg has five sections. To extend a leg, release
the flip-lever locks (L) and slide
L
leg sections out to the desired
length. Press the flip-lever back
down to lock a section in place.
Adjusting the variable leg angle spread
Adjust the tripod leg angles for ease of use in
various scenarios. Push
I
the leg release button (I)
and lift the leg upward to
one of two different angle
positions. Repeat with
other legs as needed.
Remove the bottom section of the two-piece
center column to keep the head closer to the
ground when viewing at the lowest position.
Adjusting the center column
Change the position of the center column (J) to gain additional height.
Unlock the center column by rotating the collar (G) in a counter-clockwise
direction. Maneuver the center column to the desired height and lock in
place by rotating the collar in a clockwise direction.
windy conditions by hanging a counterweight (not supplied) from the center
column accessory hook (K).
Using the level
Use the leveling bubble (H) on the shoulder mount to gauge your alignment
and allow for optimum viewing and photography. The tripod will be level
when the bubble is within the black circle.
tabilize the tripod in
S
©Vortex Optics USA 2009
Warranty and Service
This product is warranted to be
free of defects in materials and
workmanship for three years
after purchase. Vortex Optics
will repair or replace such
product or part thereof that,
upon our inspection, is found
to be defective in materials or
workmanship.
If you need assistance using your
tripod, please contact:
Vortex Optics
2120 West Greenview Drive
Middleton, WI 53562
800-426-0048
service@vortexoptics.com
