ATTUATORE LINEARE ELETTROMECCANICO PER CANCELLI A BATTENTE
ISTRUZIONI E AVVERTENZE PER L`INSTALLAZIONE, L`USO E LA MANUTENZIONE
LINEAR ELECTROMECHANICAL OPERATOR FOR SWING GATESСТВОРЧАТЫХ
INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCEОБСЛУЖИВАНИЮ
ACTIONNEUR LINEAIRE ELECTROMECANIQUE POUR PORTAILS A
INSTRUCTIONS ET CONSEILS POUR L'INSTALLATION, L'UTILISATION ET
ACTUADOR LINEAL ELECTROMECÁNICO PARA CANCELAS
INSTRUCCIONES Y ADVERTENCIAS PARA LA INSTALACIÓN, EL USO Y EL
MOTOR LINEAR ELECTROMECÂNICO PARA PORTÕES DE BATENTE
INSTRUÇÕES E ADVERTÊNCIAS PARA A INSTALAÇÃO, USO E A MANUTENÇÃO
ELEKTROMECHANISCHER DREHTORANTRIEBСТВОРЧАТЫХ ВОРОТ
ANLEITUNGEN UND HINWEISE FÜR INSTALLATION, GEBRAUCH UND WARTUNG
МЕХАНИЗМ SIŁOWNIK LINEARNY ELEKTROMAGNETYCZNY DO BRAM
INSTRUKCJA MONTAŻU, UŻYTKOWANIA I KONSERWACJIОБСЛУЖИВАНИЮ
ЛИНЕЙНЫЙ ЭЛЕКТРОМЕХАНИЧЕСКИЙ ИСПОЛНИТЕЛЬНЫЙ
ИНСТРУКЦИИ и РЕКОМЕНДАЦИИ ПО МОНТАЖУ, ИСПОЛЬЗОВАНИЮ И ТЕХНИЧЕСКОМУ
ELEKTROMECHANIKUS KAROS MEGHAJTÁS SZÁRNYAS KAPUKHOZ
UTASÍTÁSUK ÉS FIGYELMEZTETÉSEK TELEPÍTÉSHEZ, HASZNÁLATHOZ ÉS KARBANTARTÁSHOZ
WWW.Roham-tech.ir
OP3-OP5
Advertisement
Related Manuals for LIFE home integration OPTIMO OP3 Series
Summary of Contents for LIFE home integration OPTIMO OP3 Series
- Page 1 OP3-OP5 ATTUATORE LINEARE ELETTROMECCANICO PER CANCELLI A BATTENTE ISTRUZIONI E AVVERTENZE PER L`INSTALLAZIONE, L`USO E LA MANUTENZIONE LINEAR ELECTROMECHANICAL OPERATOR FOR SWING GATESСТВОРЧАТЫХ INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCEОБСЛУЖИВАНИЮ ACTIONNEUR LINEAIRE ELECTROMECANIQUE POUR PORTAILS A INSTRUCTIONS ET CONSEILS POUR L’INSTALLATION, L’UTILISATION ET ACTUADOR LINEAL ELECTROMECÁNICO PARA CANCELAS INSTRUCCIONES Y ADVERTENCIAS PARA LA INSTALACIÓN, EL USO Y EL MOTOR LINEAR ELECTROMECÂNICO PARA PORTÕES DE BATENTE...
-
Page 2: Technical Features
1 TECHNICAL FEATURES LIFE home integration reserves the right to make changes to technical characteristics at any time and without prior notice, without changing the product’s intended use and function. OPTIMO: Irreversible electromechanical operator with 230V or 24V power supply for swing gates with or without optical encoder, with or without limit switches and with stop plates. - Page 3 OP3= 745 mm OP5= 895 mm OP3 - OP3L - OP3 UNI - OP3L UNI - OP324 - OP324 UNI OP5 - OP5L - OP5UNI - OP5L UNI - OP524 - OP524 Max leaf weight (kg) Max leaf length (m) Max leaf length (m) Max leaf weight (kg) 2,00...
- Page 4 Check that the distance “C” on the gate support structure is no greater than the value given in the table below. If the distance is higher than this value, it is necessary to intervene by making a niche in the structure to obtain the indicated value. This is to avoid the linear operator colliding with the edge of the structure during closure.
- Page 5 2.4 Positioning the operator and stop plate adjustment Release the operator as indicated in the RELEASING THE OPERATOR chapter. Lift the operator and insert the nut screw bushing support pin (3) into the hole on the front bracket (2). Insert the bushing (4) into the chosen hole on the rear bracket (1) and thread the operator fork (5) on to the bracket, aligning the hole with the bushing.
-
Page 6: Wiring And Connections
3.0 WIRING AND CONNECTIONS • Before commencing wiring and connection work, read the SAFETY INSTRUCTIONS AND WARNINGS chapter carefully. • The operator must be connected to Life control units only. INTEGRATED 433.92 MHz LIFE PLUG-IN RADIO OPERATORS RADIO RECEIVER RECEIVER OP3 - OP3L - OP5 - OP5L GE1A -GE2A GE1R -GE2R... - Page 7 DESCRIZIONE COMPONENTI OP/OP5 DESCRIPTION OF OP3/OP5 COMPONENTS DESCRIPTIONS PARTICULIERES OP3 / OP5 DESCRIPCIONES DE LOS DETALLES DEL OP3 / OP5 DESCRIÇÕES PARTICULARES OP3 / OP5 BESONDERE BESCHREIBUNGEN OP3 / OP5 OPIS SZCZEGÓŁOWY OP3 / OP5 ОПИСАНИЕ ОСОБЕННОСТЕЙ OP3 / OP5 1) 5RI0870000 OP3-OP5-OP3UNI-OP5UNI OP3/OP5 RÉSZLETEZETT ROBBANTOTT 2) 5RI0880000 OP3L-OP3LUNI-OP5L-OP5LUNI...
- Page 8 13) 5RI0990000 OPTIMO 14) 5RI01000000 OPTIMO 15-16 15) 5RI01010000 OP3-OP3L-OP324 17) 5RI01030000 OPTIMO 16) 5RI01020000 OP5-OP5L-OP524 19) 5RI01060000 OPTIMO 18) 5RI01040000 OPTIMO 20) 5RI01070000 OPTIMO 22) 5RI01080000 OP3-OP3L-OP3UNI-OP3LUNI-OP5-OP5L OP5UNI-OP5LUNI 23) 5RI2750000 OP3UNI-OP3LUNI-OP324UNI-OP5UNI 22) 5RI01090000 OPTIMO OP5LUNI-OP524UNI WWW.Roham-tech.ir...
