4. Power and Heat Management

All boosters are fully protected against any thermal failure and
excessive internal temperatures. The following information is given
to allow you to run long experiments safely, without the possibility
of being interrupted by overheating.
4.1

BOOSTER VARIANTS

In this series of boosters, three variants provide a range of voltages and currents
for sourcing (cell charging) and sinking (cell discharging) . A fourth variant is
only for sinking. These variants and their operating ranges are listed in Table 4-1.
Variant
Booster
12V/20A
Booster
24V/10A
Booster 50V/5A
Booster
50V/25A/125W
Only for sinking
Booster
100V/3A
14906001_AA 12-09-07
Table 4-1 Operating Ranges of Booster Variants
Voltage
Range
-3V to +12V
-3V to +24V
-3V to +50V
-3V to +50V
-3V to +100V
Continuity at 20°C
Current
Positive
Range
Current
(Source)
-20A to
Continuous at
+20A
12V, +20A
6V, +20A
0V, +20A
-10A to
Continuous at
+10A
24V, +10A
12V, +10A
0V, +10A
-5A to +5A
Continuous at
50V, +5A
25V, +5A
1 hour at
0V, +5A
-25A to 0A
Not applicable
-3A to +3A
Continuous at
100V, +3A
50V, +3A
0V, +3A
Negative Current
(Sink)
Continuous at 12V,
-16A
30 min. at
12V, -20A.
Continuous at 24V,
-8A
30 min. at
24V, -10A.
Continuous at
50V, -3A
45 min. at 50V, -4A
10 min. at 50V, -5A
Continuous at
50V, -3A or in
range defined by
Figure 4-1.
45 min. at 50V, -4A
10 min. at 50V, -5A
Continuous at
100V, -3A
Continuous at
50V, -3A
Continuous at
0V, -3A
4-1
