Booster User Guide

3. Running an Experiment

Once the booster is connected to the potentiostat and the load, it is ready for use.
The recommended procedure is:
1. Connect the equipment but leave it disconnected from the cell.
2. Turn on the
settle for 30 minutes.
3. Connect the booster to the cell.
4. Check that the
is not illuminated (See Figure 3-1). The
power up but this does not indicate an error, and tests may still be safely
started in this condition.
5. Run the experiment. (See the appropriate User Guide for general guidance.)
6. Observe the front panel LEDs (Section 3.1) to ensure that the booster is
operating correctly.
14906001_AA 12-09-07
switch, on the rear panel of the booster, and leave it to
MAINS
button is not depressed, and the
STOP
Figure 3-1 Front panel controls of the booster.
Over Temperature
LED may be on after a
Overload
LED
3-1
