Unit: mm (inch)
57.3 (2
)
1/4
44 (1
)
23/32
MP33 ( C )
MP31 ( C )
65 (2
)
5/6
MP35 ( C )
NOTE 2
MP73 ( C )
MP71 ( C )
MP8 ( C )
MP71 ( C )
NOTE 2
MP1 ( C )
MP22 ( C )
7 - 2
Grease
NOTE 1 :
Once the VR BOARD is removed from the front panel,
grease must be applied to the area described as above
when assembling.
Manufacture : Shin-Etsu Chemical
Type
: G-501
NOTE 1
MP32 ( C )
VR BOARD
MP18 ( C )
J416 ( MI )
MP51 ( C )
MIC BOARD
MP52 ( C )
MP10 ( C )
SP1 ( C )
MP681 ( M )
MP21 ( C )
MP69 ( C )
W470 ( MI )
MP47 ( C )
W3 ( C )
MP47 ( C )
MP77 ( C )
MAIN UNIT
MP47 ( C )
EP681 ( M )
DS681 ( M )
NOTE 2 :
When replacing the screws, 10 - 12 kg of torque
MUST be applied to ensure water resistance.
EP1 ( A )
MP73
MP80 ( C )
MP46 ( C )
J41 ( C )
MP75 ( C )
MP74 ( C )
MP74 ( C )
MP26 ( C )
MP23 ( C )
MP25 ( C )
MP74 ( C )
MP24 ( C )
MP41 ( C )
MP76 ( C )
UNIT abbreviation ( C ) : CHASSIS PARTS, ( M ) : MAIN UNIT, ( MI ) : MIC, ( A ) : ACCESSORIES
NOTE 2
MP71 ( C )
MP66 ( C )
NOTE 2
MP71 ( C )
MP73
MP20 ( C )
NOTE 2
MP70 ( C )
EP4 ( A )
