Western Products, PO Box 245038, Milwaukee, WI 53224-9538 • www.westernplows.com
October 1, 2018
Lit. No. 68660, Rev. 06
Low-Profi le Tailgate Spreader
Model 110, 1000 & 2000
Owner's Manual
Original Instructions
CAUTION
Read this document before operating
or servicing the spreader.
This manual is for WESTERN
Model 110, 1000 & 2000 Low-Profi le Tailgate Spreaders
®
with serial numbers 7192 and higher (Model 110), 10001–10002 (Model 1000), and 20237–20363 (Model 2000).
This manual supersedes all editions with an earlier date.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Western 110

Summary of Contents for Western 110

  • Page 1 This manual is for WESTERN Model 110, 1000 & 2000 Low-Profi le Tailgate Spreaders ® with serial numbers 7192 and higher (Model 110), 10001–10002 (Model 1000), and 20237–20363 (Model 2000). This manual supersedes all editions with an earlier date.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PREFACE ..............4 OPERATING THE SPREADER ........ 11 Owner's Information Form ........4 Spreader Controls ..........11 SAFETY ..............5 ON/OFF Control ........... 11 Safety Defi nitions ..........5 Variable Speed Control ........ 12 Warning/Caution Labels ........5 Driving and Spreading on Snow and Ice ....

  • Page 4: Preface

    PREFACE This manual has been prepared to acquaint you with When service is necessary, bring your spreader to the safety information, operation, and maintenance of your distributor. They know your spreader best and are your new tailgate spreader. Please read this manual interested in your complete satisfaction.

  • Page 5: Safety

    SAFETY SAFETY DEFINITIONS WARNING/CAUTION LABELS Become familiar with and inform users about the WARNING warning and caution labels on the spreader. Indicates a potentially hazardous situation that, if not avoided, could result in death or NOTE: If labels are missing or cannot be read, see serious personal injury.

  • Page 6: Serial Number Label

    SAFETY SERIAL NUMBER LABEL SAFETY PRECAUTIONS Improper installation and operation could cause personal injury and/or equipment and property damage. Read and understand labels and the Owner's Manual before installing, operating, or making adjustments. WARNING • Driver to keep bystanders minimum of 25 feet away from operating spreader.

  • Page 7: Fuses

    SAFETY PERSONAL SAFETY CAUTION • Do not operate a spreader in need of • Remove ignition key and put the vehicle in PARK maintenance. or in gear to prevent others from starting the • Before operating the spreader, reassemble vehicle during installation or service. any parts or hardware removed for cleaning •...

  • Page 8: Ventilation

    SAFETY VENTILATION TORQUE CHART WARNING CAUTION Vehicle exhaust contains lethal fumes. Read instructions before assembling. Breathing these fumes, even in low Fasteners should be fi nger tight until concentrations, can cause death. Never instructed to tighten according to the Torque operate a vehicle in an enclosed area without Chart.

  • Page 9: Loading

    Material densities are approximate and are based on dry, loose material. It is the responsibility of the operator to know the weight of the material to be spread and the vehicle carrying capacity. Model 110 Model 1000 Model 2000 9.0 ft 8.0 ft...

  • Page 10: Mounting The Spreader

    MOUNTING THE SPREADER SWING AWAY SPREADER ® CAUTION During removal or mounting, securely grip spreader to avoid dropping. NOTE: The spreader shall be installed according to instructions supplied. Your local outlet is trained to provide this service and service your spreader with factory original parts.

  • Page 11: Operating The Spreader

    OPERATING THE SPREADER SPREADER CONTROLS CAUTION Do not swing spreader with material in the There are two control options: the ON/OFF Control hopper. and the Variable Speed Control. ON/OFF Control NOTE: Always place the cover on the hopper to prevent moisture buildup. Do not let the spreader sit idle with material in the hopper for an extended period of time.

  • Page 12: Variable Speed Control

    OPERATING THE SPREADER Variable Speed Control DRIVING AND SPREADING ON SNOW AND ICE ON/OFF Switch Speed (emergency stop when required) Control CAUTION Drinking and then driving or spreading is very dangerous. Your refl exes, perceptions, attentiveness, and judgment can be affected by even a small amount of alcohol.

  • Page 13: Removing The Spreader

    REMOVING THE SPREADER SWING AWAY MOUNT ® CAUTION Empty the hopper before removing the Removing the Spreader spreader. 1. Unplug the spreader and CHMSL (if equipped). CAUTION 2. Remove the hitch pin from the latch-side hinge pin. During removal or mounting, securely grip spreader to avoid dropping.

  • Page 14: Maintenance

    MAINTENANCE PRESEASON CHECK 4. If bearings pass inspection be sure to thoroughly grease them with a good quality multipurpose grease. See "Bearing and Set Screw CAUTION Maintenance" later in this section. Disconnect electric power at spreader electrical wiring harness connection and tag 5.

  • Page 15: Postseason Maintenance

    MAINTENANCE POSTSEASON MAINTENANCE DRIVE BELT REPLACEMENT CAUTION CAUTION Disconnect electric power at spreader Disconnect electric power at spreader electrical wiring harness connection and tag electrical wiring harness connection and tag out if required before servicing or performing out if required before servicing or performing maintenance.

  • Page 16: Bearing And Set Screw Maintenance

    MAINTENANCE BEARING & SET SCREW MAINTENANCE FUSE REPLACEMENT See the Harness Wiring Diagram on the following CAUTION page for fuse location. Disconnect electric power at spreader electrical wiring harness connection and tag If a problem should occur and fuse replacement is out if required before servicing or performing necessary, the replacement fuse must be of the same maintenance.

  • Page 17: 2-Pin Harness Wiring Diagram

    2-PIN HARNESS WIRING DIAGRAM – LOW-PROFILE SPREADERS CHMSL Speed Control Black White White Black Black Vehicle Stoplight Harness Fuse Fuse Holder Butt White Connector Black Power Lead Battery Harness Black Vehicle Harness Vehicle Wiring Harness Spreader Wiring Harness 12V DC (0.4kW motor) CHMSL Orange Black...

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE For control operation instructions, refer to the Operating the Spreader section of this manual. Problem Possible Cause Suggested Solution Spreader control is turned OFF. Turn the spreader control ON. Spreader control circuit breaker is Turn the control OFF. Reset the circuit tripped (ON/OFF control only).
  • Page 20 Western Products reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifi cations used. Western Products or the vehicle manufacturer may require or recommend optional equipment for spreaders. Do not exceed vehicle ratings with a spreader. Western Products offers a limited warranty for all spreaders and accessories.
