Tektronix Phaser 840 Instruction Sheet

Adding Plus Features to a standard Phaser 840 —
Upgrade Kit Z840FP
Installing the Z840FP upgrade provides the printer with
board, referred to as a SCSI riser board. The presence of the SCSI riser board and the extra memory enables faster
image processing, higher resolution 1200 x 600 dots-per-inch High Resolution/Photo printing and automatic
duplex for two-sided printing. With the upgrade, the printer also supports image pipelining for faster print job
throughput and Check Print Preview for proofing the first print of a job. The SCSI interface allows connecting a
scanner and an external hard drive to the printer. With either an internal or external hard drive attached, the Plus
upgrade enables fast print collation.

Static electricity precautions

On-site installation
©
Copyright 1998 by Tektronix, Inc.. All rights reserved.
Service personnel: Plug in the ground adapter (003-1501-00) in an AC
outlet. Connect the anti-static mat (006-7056-00) to the adapter's
groundplug.
Service personnel: Put on your anti-static wrist strap and connect it to
the anti-static mat.
Leave the printer plugged into its power outlet; this preserves a
ground path for static discharges.
Touch the printer's bare metal frame often to discharge static
electricity from your body.
Handle the circuit board(s) by their edges only.
Do not lay the board(s) on a metal surface.
Avoid wearing nylon or polyester clothing; they generate static
electricity.
Professional, on-site installation is just a phone call away. Productivity is
important to your business success – so when you need it done right, the first
time – call Tektronix. Tektronix' on-site installation delivers what you've been
looking for: expert service technicians who provide quality, on-site product
installation. In the United States and Canada, call 1 800-835-6100.
Do not install this kit if you are not comfortable modifying electronic equipment.
You will be liable for any damage caused to the printer.
32 Mbytes of additional memory and a SCSI interface
Instruction Sheet
®
Phaser 840
075-0418-AA
